南方泵业NIH系列化工泵，材质，机封，冷却系统都可按客户需求非标定制

作者：admin 浏览量：254 来源：本站时间：2026-01-05 13:58:18

信息摘要：

南方泵业NIH系列化工泵，材质，机封，冷却系统都可按客户需求非标定制，详情请咨询：4001-077-588


型号	额定流量 (m³/h)	额定扬程 (m)	额定效率 (%)	额定功率 (kW)	额定转速 (rpm)	叶轮外径	进口口径	出口口径	电机功率 (kW)	额定电流(A)	机械密封	电机重量(kg)
NIH40-25-125/1.1	6	14	35	0.65	2900	105	40	25	1.1	2.4	ZJ-KTN-28-B/D1/C-4	25
NIH40-25-125/1.5	6	20	38	0.86	2900	122	40	25	1.5	3.1	ZJ-KTN-28-B/D1/C-4	31
NIH40-25-125/2.2	6	22	39	0.92	2900	127	40	25	2.2	4.4	ZJ-KTN-28-B/D1/C-4	36
NIH40-25-160/1.5	6	21	25	1.4	2900	121	40	25	1.5	3.1	ZJ-KTN-28-B/D1/C-4	31
NIH40-25-160/2.2	6	30	29	1.7	2900	142	40	25	2.2	4.4	ZJ-KTN-28-B/D1/C-4	36
NIH40-25-160/3	6	37	31	2	2900	155	40	25	3	5.9	ZJ-KTN-28-B/D1/C-4	45
NIH40-25-200/4	6	35	25	2.3	2900	159	40	25	4	7.7	ZJ-KTN-28-B/D1/C-4	60
NIH40-25-200/5.5	6	50	29	2.8	2900	185	40	25	5.5	10.4	ZJ-KTN-28-B/D1/C-4	78
NIH40-25-200/7.5	6	53	30	2.9	2900	190	40	25	7.5	14	ZJ-KTN-28-B/D1/C-4	85
NIH50-32-125/1.5	12.5	14.5	41	1.2	2900	116	50	32	1.5	3.1	ZJ-KTN-32-B/D1/C-4	31
NIH50-32-125/2.2	12.5	20.5	46	1.5	2900	133	50	32	2.2	4.4	ZJ-KTN-32-B/D1/C-4	36
NIH50-32-125/3	13	22.5	48	1.7	2900	138	50	32	3	5.9	ZJ-KTN-32-B/D1/C-4	45
NIH50-32-160/3	12.5	27	35	2.6	2900	150	50	32	3	5.9	ZJ-KTN-32-B/D1/C-4	45
NIH50-32-160/4	12.5	30	36	2.8	2900	159	50	32	4	7.7	ZJ-KTN-32-B/D1/C-4	60
NIH50-32-160/5.5	14.5	34	43	3.1	2900	165	50	32	5.5	10.4	ZJ-KTN-32-B/D1/C-4	78
NIH50-32-200/5.5	12.5	39	36	3.7	2900	167	50	32	5.5	10.4	ZJ-KTN-32-B/D1/C-4	78
NIH50-32-200/7.5	12.5	50	40	4.3	2900	186	50	32	7.5	14	ZJ-KTN-32-B/D1/C-4	85
NIH50-32-200/11	15	62.5	45	5.7	2900	205	50	32	11	20.3	ZJ-KTN-32-B/D1/C-4	150
NIH50-32-200/0.75	6.3	9.8	30	0.55	1450	167	50	32	0.75	1.8	ZJ-KTN-32-B/D1/C-4	25
NIH50-32-200/1.1	6.3	12.5	34	0.63	1450	186	50	32	1.1	2.6	ZJ-KTN-32-B/D1/C-4	33
NIH50-32-200/1.5	7.5	15.6	39	0.82	1450	205	50	32	1.5	3.4	ZJ-KTN-32-B/D1/C-4	38
NIH50-32-250/11	12.5	56	30	6.4	2900	205	50	32	11	20.3	ZJ-KTN-38-B/D1/C-4	150
NIH50-32-250/15	12.5	80	36	7.6	2900	239	50	32	15	27.4	ZJ-KTN-38-B/D1/C-4	165
NIH50-32-250/18.5	16	85	39	9.5	2900	245	50	32	18.5	33.7	ZJ-KTN-38-B/D1/C-4	173
NIH50-32-250/1.5	6.3	14	24	0.99	1450	205	50	32	1.5	3.4	ZJ-KTN-38-B/D1/C-4	38
NIH50-32-250/2.2	6.3	20	30	1.1	1450	239	50	32	2.2	4.7	ZJ-KTN-38-B/D1/C-4	44
NIH50-32-250/3	8	21.3	33	1.4	1450	245	50	32	3	6.3	ZJ-KTN-38-B/D1/C-4	50
NIH65-40-200/7.5	25	35	50	4.8	2900	165	65	40	7.5	14	ZJ-KTN-32-B/D1/C-4	85
NIH65-40-200/11	25	50	60	5.7	2900	192	65	40	11	20.3	ZJ-KTN-32-B/D1/C-4	150
NIH65-40-200/15	30	53	64	6.8	2900	198	65	40	15	27.4	ZJ-KTN-32-B/D1/C-4	165
NIH65-40-200/1.1	12.5	8.8	44	0.68	1450	165	65	40	1.1	2.6	ZJ-KTN-32-B/D1/C-4	33
NIH65-40-200/1.5	12.5	12.5	54	0.79	1450	192	65	40	1.5	3.4	ZJ-KTN-32-B/D1/C-4	38
NIH65-40-200/2.2	15	13.3	58	0.93	1450	198	65	40	2.2	4.7	ZJ-KTN-32-B/D1/C-4	44
NIH65-40-250/15	25	56	37	10.3	2900	203	65	40	15	27.4	ZJ-KTN-38-B/D1/C-4	165
NIH65-40-250/18.5	25	80	45	12.1	2900	237	65	40	18.5	33.7	ZJ-KTN-38-B/D1/C-4	173
NIH65-40-250/30	30	90	50	14.7	2900	248	65	40	30	54.2	ZJ-KTN-38-B/D1/C-4	290
NIH65-40-250/2.2	12.5	14	31	1.5	1450	203	65	40	2.2	4.7	ZJ-KTN-38-B/D1/C-4	44
NIH65-40-250/3	12.5	20	39	1.7	1450	237	65	40	3	6.3	ZJ-KTN-38-B/D1/C-4	50
NIH65-40-250/4	15	22.5	44	2.1	1450	248	65	40	4	8.3	ZJ-KTN-38-B/D1/C-4	65
NIH65-40-315/30	25	87.5	28	21.3	2900	254	65	40	30	54.2	ZJ-KTN-50-B/D1/C-4	290
NIH65-40-315/37	25	125	36	23.7	2900	296	65	40	37	66.6	ZJ-KTN-50-B/D1/C-4	310
NIH65-40-315/45	30	139	41	27.7	2900	310	65	40	45	80.9	ZJ-KTN-50-B/D1/C-4	370
NIH65-40-315/4	12.5	22	23	3.3	1450	254	65	40	4	8.3	ZJ-KTN-50-B/D1/C-4	65
NIH65-40-315/5.5	12.5	32	31	3.5	1450	296	65	40	5.5	11.4	ZJ-KTN-50-B/D1/C-4	80
NIH65-40-315/7.5	15	34.8	35	4.1	1450	310	65	40	7.5	15.2	ZJ-KTN-50-B/D1/C-4	92
NIH65-50-125/3	25	15	54	1.9	2900	116	65	50	3	5.9	ZJ-KTN-32-B/D1/C-4	45
NIH65-50-125/4	25	20	60	2.3	2900	131	65	50	4	7.7	ZJ-KTN-32-B/D1/C-4	60
NIH65-50-125/5.5	30	21	62	2.8	2900	138	65	50	5.5	10.4	ZJ-KTN-32-B/D1/C-4	78
NIH65-50-160/5.5	25	26	46.5	3.8	2900	149	65	50	5.5	10.4	ZJ-KTN-32-B/D1/C-4	78
NIH65-50-160/7.5	25	32	49	4.4	2900	163	65	50	7.5	14	ZJ-KTN-32-B/D1/C-4	85
NIH65-50-160/11	25	34.5	53	4.4	2900	168	65	50	11	20.3	ZJ-KTN-32-B/D1/C-4	150
NIH80-50-200/15	50	27	59	6.2	2900	160	80	50	15	27.4	ZJ-KTN-32-B/D1/C-4	165
NIH80-50-200/18.5	50	50	66	10.3	2900	201	80	50	18.5	33.7	ZJ-KTN-32-B/D1/C-4	173
NIH80-50-200/30	55	50	68.5	11	2900	204	80	50	30	54.2	ZJ-KTN-32-B/D1/C-4	290
NIH80-50-200/2.2	25	6.8	53	0.87	1450	160	80	50	2.2	4.7	ZJ-KTN-32-B/D1/C-4	44
NIH80-50-200/3	25	12.5	60	1.4	1450	201	80	50	3	6.3	ZJ-KTN-32-B/D1/C-4	50
NIH80-50-200/4	27.5	12.5	62.5	1.5	1450	204	80	50	4	8.3	ZJ-KTN-32-B/D1/C-4	65
NIH80-50-250/22	50	56	48	15.9	2900	206	80	50	22	40	ZJ-KTN-38-B/D1/C-4	210
NIH80-50-250/30	50	80	56	19.5	2900	240	80	50	30	54.2	ZJ-KTN-38-B/D1/C-4	290
NIH80-50-250/45	60	84	62	22.2	2900	248	80	50	45	80.9	ZJ-KTN-38-B/D1/C-4	370
NIH80-50-250/3	25	14	42	2.3	1450	206	80	50	3	6.3	ZJ-KTN-38-B/D1/C-4	50
NIH80-50-250/4	25	20	50	2.7	1450	240	80	50	4	8.3	ZJ-KTN-38-B/D1/C-4	65
NIH80-50-250/5.5	30	21	56	3.1	1450	248	80	50	5.5	11.4	ZJ-KTN-38-B/D1/C-4	80
NIH80-50-315/37	50	87.5	43	27.7	2900	260	80	50	37	66.6	ZJ-KTN-50-B/D1/C-4	310
NIH80-50-315/55	50	125	50	34	2900	303	80	50	55	98.5	ZJ-KTN-50-B/D1/C-4	510
NIH80-50-315/75	60	130	55	38.6	2900	310	80	50	75	133.9	ZJ-KTN-50-B/D1/C-4	620
NIH80-50-315/5.5	25	22	37	4.1	1450	260	80	50	5.5	11.4	ZJ-KTN-50-B/D1/C-4	80
NIH80-50-315/7.5	25	32	44	5	1450	303	80	50	7.5	15.2	ZJ-KTN-50-B/D1/C-4	92
NIH80-50-315/11	30	32.5	49	5.4	1450	310	80	50	11	21.6	ZJ-KTN-50-B/D1/C-4	160
NIH80-65-125/5.5	50	11	64	2.3	2900	115	80	65	5.5	10.4	ZJ-KTN-32-B/D1/C-4	78
NIH80-65-125/7.5	50	20	70	3.9	2900	136	80	65	7.5	14	ZJ-KTN-32-B/D1/C-4	85
NIH80-65-125/11	55	20	74	4.1	2900	140	80	65	11	20.3	ZJ-KTN-32-B/D1/C-4	150
NIH80-65-160/7.5	50	24	67	4.9	2900	148	80	65	7.5	14	ZJ-KTN-32-B/D1/C-4	85
NIH80-65-160/11	50	32	69	6.3	2900	163	80	65	11	20.3	ZJ-KTN-32-B/D1/C-4	150
NIH80-65-160/15	60	34	73	7.6	2900	170	80	65	15	27.4	ZJ-KTN-32-B/D1/C-4	165
NIH100-65-200/22	100	26	60	11.8	2900	155	100	65	22	40	ZJ-KTN-38-B/D1/C-4	210
NIH100-65-200/30	100	50	71	19.2	2900	195	100	65	30	54.2	ZJ-KTN-38-B/D1/C-4	290
NIH100-65-200/45	120	60	75.5	26	2900	210	100	65	45	80.9	ZJ-KTN-38-B/D1/C-4	370
NIH100-65-200/3	50	6.5	54	1.6	1450	155	100	65	3	6.3	ZJ-KTN-38-B/D1/C-4	50
NIH100-65-200/4	50	12.5	65	2.6	1450	195	100	65	4	8.3	ZJ-KTN-38-B/D1/C-4	65
NIH100-65-200/5.5	60	15	69.5	3.5	1450	210	100	65	5.5	11.4	ZJ-KTN-38-B/D1/C-4	80
NIH100-65-250/37	100	56	58	26.3	2900	209	100	65	37	66.6	ZJ-KTN-38-B/D1/C-4	310
NIH100-65-250/55	100	80	68	32	2900	244	100	65	55	98.5	ZJ-KTN-38-B/D1/C-4	510
NIH100-65-250/75	120	89	73.5	39.6	2900	260	100	65	75	133.9	ZJ-KTN-38-B/D1/C-4	620
NIH100-65-250/5.5	50	14	52	3.7	1450	209	100	65	5.5	11.4	ZJ-KTN-38-B/D1/C-4	80
NIH100-65-250/7.5	50	20	62	4.4	1450	244	100	65	7.5	15.2	ZJ-KTN-38-B/D1/C-4	92
NIH100-65-250/11	60	22.3	67.5	5.4	1450	260	100	65	11	21.6	ZJ-KTN-38-B/D1/C-4	160
NIH100-65-315/75	100	87.5	55	43.4	2900	248	100	65	75	133.9	ZJ-KTN-60-B/D1/C-4	620
NIH100-65-315/90	100	125	61	55.8	2900	289	100	65	90	160.4	ZJ-KTN-60-B/D1/C-4	680
NIH100-65-315/110	110	146	63	69.5	2900	310	100	65	110	195.6	ZJ-KTN-60-B/D1/C-4	1120
NIH100-65-315/11	50	22	49	6.1	1450	248	100	65	11	21.6	ZJ-KTN-60-B/D1/C-4	160
NIH100-65-315/15	50	32	55	7.9	1450	289	100	65	15	28.9	ZJ-KTN-60-B/D1/C-4	180
NIH100-65-315/18.5	55	36.5	57	9.6	1450	310	100	65	18.5	35.1	ZJ-KTN-60-B/D1/C-4	205
NIH100-65-400/15	50	35	45	10.6	1450	318	100	65	15	28.9	ZJ-KTN-60-B/D1/C-4	180
NIH100-65-400/18.5	50	50	50	13.6	1450	371	100	65	18.5	35.1	ZJ-KTN-60-B/D1/C-4	205
NIH100-65-400/22	60	55	56.5	16	1450	390	100	65	22	41.6	ZJ-KTN-60-B/D1/C-4	235
NIH100-80-125/11	100	14	60	6.4	2900	121	100	80	11	20.3	ZJ-KTN-32-B/D1/C-4	150
NIH100-80-125/15	100	20	65	8.4	2900	141	100	80	15	27.4	ZJ-KTN-32-B/D1/C-4	165
NIH100-80-125/18.5	100	20.5	66	8.5	2900	143	100	80	18.5	33.7	ZJ-KTN-32-B/D1/C-4	173
NIH100-80-160/15	100	22.4	67	9.1	2900	140	100	80	15	27.4	ZJ-KTN-38-B/D1/C-4	165
NIH100-80-160/18.5	100	32	72	12.1	2900	163	100	80	18.5	33.7	ZJ-KTN-38-B/D1/C-4	173
NIH100-80-160/30	115	36	76	14.8	2900	175	100	80	30	54.2	ZJ-KTN-38-B/D1/C-4	290
NIH125-80-200/30	120	26	65.5	13	2900	160	125	80	30	54.2	ZJ-KTN-38-B/D1/C-4	290
NIH125-80-200/45	150	40	74	22	2900	190	125	80	45	80.9	ZJ-KTN-38-B/D1/C-4	370
NIH125-80-200/55	160	52	76	29.8	2900	210	125	80	55	98.5	ZJ-KTN-38-B/D1/C-4	510
NIH125-80-200/5.5	60	6.5	59.5	1.8	1450	160	125	80	5.5	11.4	ZJ-KTN-38-B/D1/C-4	80
NIH125-80-200/7.5	75	10	68	3	1450	190	125	80	7.5	15.2	ZJ-KTN-38-B/D1/C-4	92
NIH125-80-200/11	80	13	70	4	1450	210	125	80	11	21.6	ZJ-KTN-38-B/D1/C-4	160
NIH125-80-250/55	150	56	65	35.2	2900	216	125	80	55	98.5	ZJ-KTN-50-B/D1/C-4	510
NIH125-80-250/75	150	80	70	46.7	2900	252	125	80	75	133.9	ZJ-KTN-50-B/D1/C-4	620
NIH125-80-250/90	150	86	73	48.1	2900	260	125	80	90	160.4	ZJ-KTN-50-B/D1/C-4	680
NIH125-80-250/7.5	75	14	59	4.8	1450	216	125	80	7.5	15.2	ZJ-KTN-50-B/D1/C-4	92
NIH125-80-250/11	75	20	64	6.4	1450	252	125	80	11	21.6	ZJ-KTN-50-B/D1/C-4	160
NIH125-80-250/15	75	21.5	67	6.6	1450	260	125	80	15	28.9	ZJ-KTN-50-B/D1/C-4	180
NIH125-80-315/90	150	87.5	57	62.8	2900	264	125	80	90	160.4	ZJ-KTN-60-B/D1/C-4	680
NIH125-80-315/132	150	125	63	81	2900	308	125	80	132	234.2	ZJ-KTN-60-B/D1/C-4	1130
NIH125-80-315/160	150	132	66	81.8	2900	315	125	80	160	283.6	ZJ-KTN-60-B/D1/C-4	1210
NIH125-80-315/15	75	22	51	8.8	1450	264	125	80	15	28.9	ZJ-KTN-60-B/D1/C-4	180
NIH125-80-315/18.5	75	32	57	11.5	1450	308	125	80	18.5	35.1	ZJ-KTN-60-B/D1/C-4	205
NIH125-80-315/22	75	33	60	11.2	1450	315	125	80	22	41.6	ZJ-KTN-60-B/D1/C-4	235
NIH125-100-200/45	200	39	81	26.2	2900	190	125	100	45	80.9	ZJ-KTN-38-B/D1/C-4	370
NIH125-100-200/55	200	50	86	31.7	2900	211	125	100	55	98.5	ZJ-KTN-38-B/D1/C-4	510
NIH125-100-200/5.5	100	8.8	70	3.4	1450	180	125	100	5.5	11.4	ZJ-KTN-38-B/D1/C-4	80
NIH125-100-200/7.5	100	12.5	73	4.7	1450	210	125	100	7.5	15.2	ZJ-KTN-38-B/D1/C-4	92
NIH125-100-200/11	115	14	75	5.8	1450	220	125	100	11	21.6	ZJ-KTN-38-B/D1/C-4	160
NIH125-100-250/75	200	56	70	43.6	2900	220	125	100	75	133.9	ZJ-KTN-50-B/D1/C-4	620
NIH125-100-250/90	200	80	74.5	58.5	2900	257	125	100	90	160.4	ZJ-KTN-50-B/D1/C-4	680
NIH125-100-250/132	200	90	74	66.3	2900	270	125	100	132	234.2	ZJ-KTN-50-B/D1/C-4	1130
NIH125-100-250/11	100	14	64	6	1450	220	125	100	11	21.6	ZJ-KTN-50-B/D1/C-4	160
NIH125-100-250/15	100	20	68.5	8	1450	257	125	100	15	28.9	ZJ-KTN-50-B/D1/C-4	180
NIH125-100-250/18.5	100	22.5	68	9	1450	270	125	100	18.5	35.1	ZJ-KTN-50-B/D1/C-4	205
NIH125-100-315/110	200	84	60	76.3	2900	281	125	100	110	195.6	ZJ-KTN-60-B/D1/C-4	1120
NIH125-100-315/160	200	120	68	96.2	2900	328	125	100	160	283.6	ZJ-KTN-60-B/D1/C-4	1210
NIH125-100-315/15	100	21	54	10.6	1450	281	125	100	15	28.9	ZJ-KTN-60-B/D1/C-4	180
NIH125-100-315/22	100	30	62	13.2	1450	328	125	100	22	41.6	ZJ-KTN-60-B/D1/C-4	235
NIH125-100-400/30	100	35	55	17.3	1450	319	125	100	30	56.5	ZJ-KTN-60-B/D1/C-4	310
NIH125-100-400/37	100	50	61	22.3	1450	371	125	100	37	69.5	ZJ-KTN-60-B/D1/C-4	370
NIH125-100-400/55	120	55	67.5	26.6	1450	390	125	100	55	101.5	ZJ-KTN-60-B/D1/C-4	520
NIH150-125-250/18.5	150	12	61	8	1450	205	150	125	18.5	35.1	ZJ-KTN-50-B/D1/C-4	205
NIH150-125-250/30	200	14	69	11	1450	230	150	125	30	56.5	ZJ-KTN-50-B/D1/C-4	310
NIH150-125-250/37	240	21	81	17	1450	270	150	125	37	69.5	ZJ-KTN-50-B/D1/C-4	370
NIH150-125-315/30	200	22.4	68	18	1450	278	150	125	30	56.5	ZJ-KTN-60-B/D1/C-4	310
NIH150-125-315/37	200	32	73	23.9	1450	324	150	125	37	69.5	ZJ-KTN-60-B/D1/C-4	370
NIH150-125-315/55	215	33	75	25.8	1450	328	150	125	55	101.5	ZJ-KTN-60-B/D1/C-4	520
NIH150-125-400/45	200	35	62	30.8	1450	352	150	125	45	84.3	ZJ-KTN-60-B/D1/C-4	405
NIH150-125-400/75	220	50	73	41	1450	410	150	125	75	136.4	ZJ-KTN-60-B/D1/C-4	650
NIH200-150-250/30	400	14	70	21.8	1450	240	200	150	30	56.5	ZJ-KTN-50-B/D1/C-4	310
NIH200-150-250/45	400	20	79	27.6	1450	280	200	150	45	84.3	ZJ-KTN-50-B/D1/C-4	405
NIH200-150-315/55	400	21	65	35.2	1450	279	200	150	55	101.5	ZJ-KTN-70-B/D1/C-4	520
NIH200-150-315/75	400	30	74	44.2	1450	325	200	150	75	136.4	ZJ-KTN-70-B/D1/C-4	650
NIH200-150-400/75	360	36	76	46.5	1450	355	200	150	90	161.7	ZJ-KTN-70-B/D1/C-4	720
NIH200-150-400/90	400	50	77	70.8	1450	399	200	150	110	195	ZJ-KTN-70-B/D1/C-4	1140
NIH200-150-400/132	400	53	78	74	1450	409	200	150	160	279.6	ZJ-KTN-70-B/D1/C-4	1230
NIH200-150-500/132	400	56	79	77.3	1450	437	200	150	132	233.8	ZJ-KTN-70-B/D1/C-4	1150
NIH200-150-500/200	400	80	82	106	1450	509	200	150	200	349.2	ZJ-KTN-70-B/D1/C-4	1320
NIH250-200-315/110	640	19.6	72	47.5	1450	283	250	200	110	195	ZJ-KTN-70-B/D1/C-4	1140
NIH250-200-315/160	640	28	81	60.3	1450	330	250	200	160	279.6	ZJ-KTN-70-B/D1/C-4	1230
NIH250-200-400/132	640	35	65	94	1450	339	250	200	132	233.8	ZJ-KTN-70-B/D1/C-4	1150
NIH250-200-400/160	640	50	75	116	1450	395	250	200	160	279.6	ZJ-KTN-70-B/D1/C-4	1230
NIH250-200-400/200	640	55	78	123	1450	412	250	200	200	349.2	ZJ-KTN-70-B/D1/C-4	1320
NIH250-200-500/200	660	52.5	66	143	1450	437	250	200	200	349.2	ZJ-KTN-80-B/D1/C-4	1320
NIH250-200-500/250	660	75	78	173	1450	510	250	200	250	436.4	ZJ-KTN-80-B/D1/C-4	1850
NIH300-250-400/200	1000	34	77	120	1450	360	300	250	200	349.2	ZJ-KTN-70-B/D1/C-4	1320
NIH300-250-400/250	1000	48	83	158	1450	417	300	250	250	436.4	ZJ-KTN-70-B/D1/C-4	1850
NIH300-250-500/250	1000	75	81.5	251	1450	475	300	250	250	436.4	ZJ-KTN-80-B/D1/C-4	1850
NIH300-250-500/315	1100	85	84	303	1450	509	300	250	315	549.9	ZJ-KTN-80-B/D1/C-4	2160

南方泵业NIH系列化工泵，材质，机封，冷却系统都可按客户需求非标定制

联系方式

二维码
