南方泵业CDMF+CMH系列组合式高压泵组，压滤机清洗专用泵，减温减压装置用泵，高压泵

作者：admin 浏览量：508 来源：本站时间：2026-01-05 14:10:30

信息摘要：

南方泵业CDMF+CMH系列组合式高压泵组，压滤机清洗专用泵，减温减压装置用泵，高压泵，详情请咨询：4001-077-588


序号	型号	额定流量 (m³/h)	额定扬程 (m)	额定效率 (%)	额定功率 (kW)	额定转速 (rpm)	叶轮外径	叶轮级数	进出口径	电机功率 (kW)	重量(kg)
1	CDMF1-2+CMH1-40	1	233	41	1.6	2900	74.5	2	DN32	0.37+2.2	89
2	CDMF1-3+CMH1-40	1	239	41	1.6	2900	74.5	3	DN32	0.37+2.2	89
3	CDMF1-4+CMH1-40	1	244	41	1.6	2900	74.5	4	DN32	0.37+2.2	90
4	CDMF1-5+CMH1-40	1	250	41	1.7	2900	74.5	5	DN32	0.37+2.2	90
5	CDMF1-6+CMH1-40	1	255	41	1.7	2900	74.5	6	DN32	0.37+2.2	91
6	CDMF1-7+CMH1-40	1	262	41	1.7	2900	74.5	7	DN32	0.37+2.2	91
7	CDMF1-8+CMH1-40	1	266	41	1.8	2900	74.5	8	DN32	0.55+2.2	93
8	CDMF1-9+CMH1-40	1	272	41	1.8	2900	74.5	9	DN32	0.55+2.2	93
9	CDMF1-10+CMH1-40	1	278	41	1.9	2900	74.5	10	DN32	0.55+2.2	94
10	CDMF1-11+CMH1-40	1	284	41	1.9	2900	74.5	11	DN32	0.55+2.2	94
11	CDMF1-12+CMH1-40	1	290	41	1.9	2900	74.5	12	DN32	0.75+2.2	97
12	CDMF1-13+CMH1-40	1	296	41	2	2900	74.5	13	DN32	0.75+2.2	97
13	CDMF1-14+CMH1-40	1	301	41	2	2900	74.5	14	DN32	0.75+2.2	98
14	CDMF1-15+CMH1-40	1	307	41	2	2900	74.5	15	DN32	0.75+2.2	98
15	CDMF1-16+CMH1-40	1	312	41	2.1	2900	74.5	16	DN32	1.1+2.2	101
16	CDMF1-17+CMH1-40	1	318	41	2.1	2900	74.5	17	DN32	1.1+2.2	101
17	CDMF1-18+CMH1-40	1	323	41	2.1	2900	74.5	18	DN32	1.1+2.2	102
18	CDMF1-19+CMH1-40	1	329	41	2.2	2900	74.5	19	DN32	1.1+2.2	102
19	CDMF1-20+CMH1-40	1	334	41	2.2	2900	74.5	20	DN32	1.1+2.2	102
20	CDMF1-21+CMH1-40	1	340	41	2.3	2900	74.5	21	DN32	1.1+2.2	102
21	CDMF1-22+CMH1-40	1	345	41	2.3	2900	74.5	22	DN32	1.1+2.2	103
22	CDMF1-23+CMH1-40	1	351	41	2.3	2900	74.5	23	DN32	1.5+2.2	109
23	CDMF1-24+CMH1-40	1	357	41	2.4	2900	74.5	24	DN32	1.5+2.2	109
24	CDMF1-25+CMH1-40	1	362	41	2.4	2900	74.5	25	DN32	1.5+2.2	110
25	CDMF1-26+CMH1-40	1	368	41	2.4	2900	74.5	26	DN32	1.5+2.2	110
26	CDMF1-27+CMH1-40	1	373	41	2.5	2900	74.5	27	DN32	1.5+2.2	111
27	CDMF1-28+CMH1-40	1	379	41	2.5	2900	74.5	28	DN32	1.5+2.2	111
28	CDMF1-29+CMH1-40	1	384	41	2.5	2900	74.5	29	DN32	1.5+2.2	112
29	CDMF1-30+CMH1-40	1	390	41	2.6	2900	74.5	30	DN32	1.5+2.2	112
30	CDMF1-31+CMH1-40	1	398	41	2.6	2900	74.5	31	DN32	2.2+2.2	115
31	CDMF1-32+CMH1-40	1	403	41	2.7	2900	74.5	32	DN32	2.2+2.2	115
32	CDMF1-33+CMH1-40	1	409	41	2.7	2900	74.5	33	DN32	2.2+2.2	115
33	CDMF1-34+CMH1-40	1	415	41	2.8	2900	74.5	34	DN32	2.2+2.2	116
34	CDMF1-35+CMH1-40	1	420	41	2.8	2900	74.5	35	DN32	2.2+2.2	116
35	CDMF1-36+CMH1-40	1	426	41	2.8	2900	74.5	36	DN32	2.2+2.2	117
36	CDMF1-37+CMH1-40	1	432	41	2.9	2900	74.5	37	DN32	2.2+2.2	117
37	CDMF1-38+CMH1-40	1	438	41	2.9	2900	74.5	38	DN32	2.2+2.2	117
38	CDMF1-39+CMH1-40	1	443	41	2.9	2900	74.5	38	DN32	2.2+2.2	118
39	CDMF1-40+CMH1-40	1	449	41	3	2900	74.5	40	DN32	2.2+2.2	118
40	CDMF3-2+CMH3-31	3	195	58	2.8	2900	82	2	DN32	0.37+3	119
41	CDMF3-3+CMH3-31	3	201	58	2.8	2900	82	3	DN32	0.37+3	119
42	CDMF3-4+CMH3-31	3	207	58	2.9	2900	82	4	DN32	0.37+3	120
43	CDMF3-5+CMH3-31	3	213	58	3	2900	82	5	DN32	0.55+3	121
44	CDMF3-6+CMH3-31	3	219	58	3.1	2900	82	6	DN32	0.55+3	122
45	CDMF3-7+CMH3-31	3	225	58	3.2	2900	82	7	DN32	0.75+3	125
46	CDMF3-8+CMH3-31	3	231	58	3.3	2900	82	8	DN32	0.75+3	125
47	CDMF3-9+CMH3-31	3	237	58	3.3	2900	82	9	DN32	1.1+3	127
48	CDMF3-10+CMH3-31	3	243	58	3.4	2900	82	10	DN32	1.1+3	128
49	CDMF3-11+CMH3-31	3	249	58	3.5	2900	82	11	DN32	1.1+3	128
50	CDMF3-12+CMH3-31	3	255	58	3.6	2900	82	12	DN32	1.1+3	129
51	CDMF3-13+CMH3-31	3	261	58	3.7	2900	82	13	DN32	1.5+3	134
52	CDMF3-14+CMH3-31	3	267	58	3.8	2900	82	14	DN32	1.5+3	135
53	CDMF3-15+CMH3-31	3	274	58	3.9	2900	82	15	DN32	1.5+3	135
54	CDMF3-16+CMH3-31	3	280	58	4	2900	82	16	DN32	1.5+3	136
55	CDMF3-17+CMH3-31	3	286	58	4	2900	82	17	DN32	2.2+3	137
56	CDMF3-18+CMH3-31	3	292	58	4.1	2900	82	18	DN32	2.2+3	138
57	CDMF3-19+CMH3-31	3	298	58	4.2	2900	82	19	DN32	2.2+3	139
58	CDMF3-20+CMH3-31	3	304	58	4.3	2900	82	20	DN32	2.2+3	139
59	CDMF3-21+CMH3-31	3	310	58	4.4	2900	82	21	DN32	2.2+3	140
60	CDMF3-22+CMH3-31	3	316	58	4.5	2900	82	22	DN32	2.2+3	140
61	CDMF3-23+CMH3-31	3	322	58	4.5	2900	82	23	DN32	2.2+3	141
62	CDMF3-24+CMH3-31	3	328	58	4.6	2900	82	24	DN32	2.2+3	141
63	CDMF3-25+CMH3-31	3	334	58	4.7	2900	82	25	DN32	3+3	152
64	CDMF3-26+CMH3-31	3	340	58	4.8	2900	82	26	DN32	3+3	152
65	CDMF3-27+CMH3-31	3	346	58	4.9	2900	82	27	DN32	3+3	153
66	CDMF3-28+CMH3-31	3	352	58	5	2900	82	28	DN32	3+3	153
67	CDMF3-29+CMH3-31	3	359	58	5.1	2900	82	29	DN32	3+3	153
68	CDMF3-30+CMH3-31	3	365	58	5.2	2900	82	30	DN32	3+3	154
69	CDMF3-31+CMH3-31	3	371	58	5.2	2900	82	31	DN32	3+3	154
70	CDMF5-2+CMH5-33	5	214	69	4.2	2900	82	2	DN32	0.37+5.5	83
71	CDMF5-3+CMH5-33	5	220	69	4.3	2900	82	3	DN32	0.55+5.5	85
72	CDMF5-4+CMH5-33	5	227	69	4.5	2900	82	4	DN32	0.55+5.5	86
73	CDMF5-5+CMH5-33	5	233	69	4.6	2900	82	5	DN32	0.75+5.5	89
74	CDMF5-6+CMH5-33	5	240	69	4.7	2900	82	6	DN32	1.1+5.5	91
75	CDMF5-7+CMH5-33	5	245	69	4.8	2900	82	7	DN32	1.1+5.5	91
76	CDMF5-8+CMH5-33	5	252	69	5	2900	82	8	DN32	1.1+5.5	92
77	CDMF5-9+CMH5-33	5	258	69	5.1	2900	82	9	DN32	1.5+5.5	97
78	CDMF5-10+CMH5-33	5	265	69	5.2	2900	82	10	DN32	1.5+5.5	98
79	CDMF5-11+CMH5-33	5	271	69	5.3	2900	82	11	DN32	1.5+5.5	98
80	CDMF5-12+CMH5-33	5	277	69	5.5	2900	82	12	DN32	2.2+5.5	101
81	CDMF5-13+CMH5-33	5	283	69	5.6	2900	82	13	DN32	2.2+5.5	101
82	CDMF5-14+CMH5-33	5	290	69	5.7	2900	82	14	DN32	2.2+5.5	102
83	CDMF5-15+CMH5-33	5	296	69	5.8	2900	82	15	DN32	2.2+5.5	102
84	CDMF5-16+CMH5-33	5	302	69	6	2900	82	16	DN32	2.2+5.5	103
85	CDMF5-17+CMH5-33	5	308	69	6.1	2900	82	17	DN32	3+5.5	114
86	CDMF5-18+CMH5-33	5	314	69	6.2	2900	82	18	DN32	3+5.5	114
87	CDMF5-19+CMH5-33	5	321	69	6.3	2900	82	19	DN32	3+5.5	115
88	CDMF5-20+CMH5-33	5	327	69	6.5	2900	82	20	DN32	3+5.5	116
89	CDMF5-21+CMH5-33	5	333	69	6.6	2900	82	21	DN32	3+5.5	123
90	CDMF5-22+CMH5-33	5	339	69	6.7	2900	82	22	DN32	4+5.5	123
91	CDMF5-23+CMH5-33	5	345	69	6.8	2900	82	23	DN32	4+5.5	124
92	CDMF5-24+CMH5-33	5	352	69	7	2900	82	24	DN32	4+5.5	124
93	CDMF5-25+CMH5-33	5	358	69	7.1	2900	82	25	DN32	4+5.5	125
94	CDMF5-26+CMH5-33	5	364	69	7.2	2900	82	26	DN32	4+5.5	125
95	CDMF5-27+CMH5-33	5	371	69	7.3	2900	82	27	DN32	4+5.5	126
96	CDMF5-28+CMH5-33	5	377	69	7.4	2900	82	28	DN32	4+5.5	126
97	CDMF5-29+CMH5-33	5	383	69	7.6	2900	82	29	DN32	5.5+5.5	146
98	CDMF5-30+CMH5-33	5	389	69	7.7	2900	82	30	DN32	5.5+5.5	147
99	CDMF5-31+CMH5-33	5	396	69	7.8	2900	82	31	DN32	5.5+5.5	147
100	CDMF5-32+CMH5-33	5	403	69	8	2900	82	32	DN32	5.5+5.5	148
101	CDMF5-33+CMH5-33	5	409	69	8.1	2900	82	33	DN32	5.5+5.5	148
102	CDMF10-1+CMH10-22	10	209	72	7.9	2900	100	1	DN50	0.75+11	214
103	CDMF10-2+CMH10-22	10	217.5	72	8.2	2900	100	2	DN50	0.75+11	215
104	CDMF10-3+CMH10-22	10	226.5	72	8.6	2900	100	3	DN50	1.1+11	218
105	CDMF10-4+CMH10-22	10	235	72	8.9	2900	100	4	DN50	1.5+11	224
106	CDMF10-5+CMH10-22	10	244	72	9.2	2900	100	5	DN50	2.2+11	228
107	CDMF10-6+CMH10-22	10	253	72	9.6	2900	100	6	DN50	2.2+11	229
108	CDMF10-7+CMH10-22	10	263	72	9.9	2900	100	7	DN50	3+11	240
109	CDMF10-8+CMH10-22	10	272	72	10.3	2900	100	8	DN50	3+11	241
110	CDMF10-9+CMH10-22	10	281	72	10.6	2900	100	9	DN50	4+11	248
111	CDMF10-10+CMH10-22	10	290	72	11	2900	100	10	DN50	4+11	249
112	CDMF10-11+CMH10-22	10	299	72	11.3	2900	100	11	DN50	4+11	250
113	CDMF10-12+CMH10-22	10	308	72	11.7	2900	100	12	DN50	4.5+11	251
114	CDMF10-13+CMH10-22	10	317	72	12	2900	100	13	DN50	5.5+11	271
115	CDMF10-14+CMH10-22	10	326	72	12.3	2900	100	14	DN50	5.5+11	272
116	CDMF10-15+CMH10-22	10	335	72	12.7	2900	100	15	DN50	5.5+11	273
117	CDMF10-16+CMH10-22	10	345	72	13.1	2900	100	16	DN50	7.5+11	282
118	CDMF10-17+CMH10-22	10	354	72	13.4	2900	100	17	DN50	7.5+11	283
119	CDMF10-18+CMH10-22	10	364	72	13.8	2900	100	18	DN50	7.5+11	284
120	CDMF10-19+CMH10-22	10	373	72	14.1	2900	100	19	DN50	7.5+11	285
121	CDMF10-20+CMH10-22	10	382	72	14.5	2900	100	20	DN50	7.5+11	286
122	CDMF10-21+CMH10-22	10	392	72	14.8	2900	100	21	DN50	7.5+11	287
123	CDMF10-22+CMH10-22	10	402	72	15.2	2900	100	22	DN50	11+11	353
124	CDMF15-1+CMH15-18	15	222	71	12.8	2900	105.2	1	DN50	1.1+15	227
125	CDMF15-2+CMH15-18	15	233.5	71	13.4	2900	105.2	2	DN50	2.2+15	235
126	CDMF15-3+CMH15-18	15	245.5	71	14.1	2900	105.2	3	DN50	3+15	246
127	CDMF15-4+CMH15-18	15	258	71	14.8	2900	105.2	4	DN50	4+15	253
128	CDMF15-5+CMH15-18	15	269	71	15.5	2900	105.2	5	DN50	4+15	255
129	CDMF15-6+CMH15-18	15	280	71	16.1	2900	105.2	6	DN50	5.5+15	277
130	CDMF15-7+CMH15-18	15	292	71	16.8	2900	105.2	7	DN50	5.5+15	278
131	CDMF15-8+CMH15-18	15	304	71	17.5	2900	105.2	8	DN50	7.5+15	285
132	CDMF15-9+CMH15-18	15	317	71	18.3	2900	105.2	9	DN50	7.5+15	286
133	CDMF15-10+CMH15-18	15	329	71	18.9	2900	105.2	10	DN50	11+15	344
134	CDMF15-11+CMH15-18	15	341	71	19.6	2900	105.2	11	DN50	11+15	346
135	CDMF15-12+CMH15-18	15	353	71	20.3	2900	105.2	12	DN50	11+15	347
136	CDMF15-13+CMH15-18	15	363	71	20.9	2900	105.2	13	DN50	11+15	349
137	CDMF15-14+CMH15-18	15	376	71	21.6	2900	105.2	14	DN50	11+15	350
138	CDMF15-15+CMH15-18	15	389	71	22.4	2900	105.2	15	DN50	15+15	366
139	CDMF15-16+CMH15-18	15	400	71	23	2900	105.2	16	DN50	15+15	368
140	CDMF15-17+CMH15-18	15	412	71	23.7	2900	105.2	17	DN50	15+15	369
141	CDMF15-18+CMH15-18	15	424	71	24.4	2900	105.2	18	DN50	15+15	371
142	CDMF20-1+CMH20-17	20	215.5	72	16.3	2900	105.5	1	DN50	1.1+18.5	255
143	CDMF20-2+CMH20-17	20	228	72	17.3	2900	105.5	2	DN50	2.2+18.5	263
144	CDMF20-3+CMH20-17	20	240	72	18.2	2900	105.5	3	DN50	4+18.5	281
145	CDMF20-4+CMH20-17	20	252	72	19.1	2900	105.5	4	DN50	5.5+18.5	303
146	CDMF20-5+CMH20-17	20	263	72	19.9	2900	105.5	5	DN50	5.5+18.5	305
147	CDMF20-6+CMH20-17	20	275	72	20.8	2900	105.5	6	DN50	7.5+18.5	314
148	CDMF20-7+CMH20-17	20	287	72	21.7	2900	105.5	7	DN50	7.5+18.5	315
149	CDMF20-8+CMH20-17	20	300	72	22.7	2900	105.5	8	DN50	11+18.5	382
150	CDMF20-9+CMH20-17	20	313	72	23.7	2900	105.5	9	DN50	11+18.5	384
151	CDMF20-10+CMH20-17	20	324	72	24.5	2900	105.5	10	DN50	11+18.5	385
152	CDMF20-11+CMH20-17	20	337	72	25.5	2900	105.5	11	DN50	15+18.5	401
153	CDMF20-12+CMH20-17	20	348	72	26.3	2900	105.5	12	DN50	15+18.5	403
154	CDMF20-13+CMH20-17	20	361	72	27.3	2900	105.5	13	DN50	15+18.5	405
155	CDMF20-14+CMH20-17	20	373	72	28.2	2900	105.5	14	DN50	15+18.5	406
156	CDMF20-15+CMH20-17	20	385	72	29.1	2900	105.5	15	DN50	18.5+18.5	423
157	CDMF20-16+CMH20-17	20	396	72	30	2900	105.5	16	DN50	18.5+18.5	425
158	CDMF20-17+CMH20-17	20	410	72	31	2900	105.5	17	DN50	18.5+18.5	427
