| 型号 | 额定流量 (m³/h) | 额定扬程 (m) | 额定效率 (%) | 额定功率 (kW) | 额定转速 (rpm) | 叶轮外径 | 叶轮级数 | 介质温度（常温型） | 介质温度（热水型） | 电机功率 (kW) | 机械密封 | 重量(kg) |
| CDM1-2 | 1 | 10.5 | 41 | 0.1 | 2900 | 74.5 | 2 | -15℃～+70℃ | -15℃～+120℃ | 0.37 | CDLA-12/WB1F16 | 19 |
| CDM1-3 | 1 | 16 | 41 | 0.1 | 2900 | 74.5 | 3 | -15℃～+70℃ | -15℃～+120℃ | 0.37 | CDLA-12/WB1F14 | 23 |
| CDM1-4 | 1 | 21.5 | 41 | 0.14 | 2900 | 74.5 | 4 | -15℃～+70℃ | -15℃～+120℃ | 0.37 | CDLA-12/WB1F14 | 24 |
| CDM1-5 | 1 | 27 | 41 | 0.17 | 2900 | 74.5 | 5 | -15℃～+70℃ | -15℃～+120℃ | 0.37 | CDLA-12/WB1F16 | 20 |
| CDM1-6 | 1 | 32.5 | 41 | 0.21 | 2900 | 74.5 | 6 | -15℃～+70℃ | -15℃～+120℃ | 0.37 | CDLA-12/WB1F14 | 25 |
| CDM1-7 | 1 | 39 | 41 | 0.25 | 2900 | 74.5 | 7 | -15℃～+70℃ | -15℃～+120℃ | 0.37 | CDLA-12/WB1F14 | 25 |
| CDM1-8 | 1 | 43.5 | 41 | 0.28 | 2900 | 74.5 | 8 | -15℃～+70℃ | -15℃～+120℃ | 0.55 | CDLA-12/WB1F14 | 27 |
| CDM1-9 | 1 | 49 | 41 | 0.32 | 2900 | 74.5 | 9 | -15℃～+70℃ | -15℃～+120℃ | 0.55 | CDLA-12/WB1F14 | 27 |
| CDM1-10 | 1 | 55 | 41 | 0.35 | 2900 | 74.5 | 10 | -15℃～+70℃ | -15℃～+120℃ | 0.55 | CDLA-12/WB1F14 | 28 |
| CDM1-11 | 1 | 61 | 41 | 0.39 | 2900 | 74.5 | 11 | -15℃～+70℃ | -15℃～+120℃ | 0.55 | CDLA-12/WB1F14 | 28 |
| CDM1-12 | 1 | 67 | 41 | 0.43 | 2900 | 74.5 | 12 | -15℃～+70℃ | -15℃～+120℃ | 0.75 | CDLA-12/WB1F14 | 31 |
| CDM1-13 | 1 | 73 | 41 | 0.47 | 2900 | 74.5 | 13 | -15℃～+70℃ | -15℃～+120℃ | 0.75 | CDLA-12/WB1F14 | 31 |
| CDM1-14 | 1 | 78 | 41 | 0.5 | 2900 | 74.5 | 14 | -15℃～+70℃ | -15℃～+120℃ | 0.75 | CDLA-12/WB1F14 | 28 |
| CDM1-15 | 1 | 84 | 41 | 0.54 | 2900 | 74.5 | 15 | -15℃～+70℃ | -15℃～+120℃ | 0.75 | CDLA-12/WB1F14 | 32 |
| CDM1-16 | 1 | 89 | 41 | 0.58 | 2900 | 74.5 | 16 | -15℃～+70℃ | -15℃～+120℃ | 1.1 | CDLA-12/WB1F14 | 31 |
| CDM1-17 | 1 | 95 | 41 | 0.61 | 2900 | 74.5 | 17 | -15℃～+70℃ | -15℃～+120℃ | 1.1 | CDLA-12/WB1F14 | 35 |
| CDM1-18 | 1 | 100 | 41 | 0.65 | 2900 | 74.5 | 18 | -15℃～+70℃ | -15℃～+120℃ | 1.1 | CDLA-12/WB1F14 | 32 |
| CDM1-19 | 1 | 106 | 41 | 0.68 | 2900 | 74.5 | 19 | -15℃～+70℃ | -15℃～+120℃ | 1.1 | CDLA-12/WB1F14 | 36 |
| CDM1-20 | 1 | 111 | 41 | 0.72 | 2900 | 74.5 | 20 | -15℃～+70℃ | -15℃～+120℃ | 1.1 | CDLA-12/WB1F14 | 33 |
| CDM1-21 | 1 | 117 | 41 | 0.75 | 2900 | 74.5 | 21 | -15℃～+70℃ | -15℃～+120℃ | 1.1 | CDLA-12/WB1F14 | 33 |
| CDM1-22 | 1 | 122 | 41 | 0.79 | 2900 | 74.5 | 22 | -15℃～+70℃ | -15℃～+120℃ | 1.1 | CDLA-12/WB1F14 | 37 |
| CDM1-23 | 1 | 128 | 41 | 0.83 | 2900 | 74.5 | 23 | -15℃～+70℃ | -15℃～+120℃ | 1.5 | CDLA-12/WB1F14 | 39 |
| CDM1-24 | 1 | 134 | 41 | 0.87 | 2900 | 74.5 | 24 | -15℃～+70℃ | -15℃～+120℃ | 1.5 | CDLA-12/WB1F14 | 39 |
| CDM1-25 | 1 | 139 | 41 | 0.9 | 2900 | 74.5 | 25 | -15℃～+70℃ | -15℃～+120℃ | 1.5 | CDLA-12/WB1F14 | 44 |
| CDM1-26 | 1 | 145 | 41 | 0.94 | 2900 | 74.5 | 26 | -15℃～+70℃ | -15℃～+120℃ | 1.5 | CDLA-12/WB1F14 | 40 |
| CDM1-27 | 1 | 150 | 41 | 0.97 | 2900 | 74.5 | 27 | -15℃～+70℃ | -15℃～+120℃ | 1.5 | CDLA-12/WB1F14 | 45 |
| CDM1-28 | 1 | 156 | 41 | 1 | 2900 | 74.5 | 28 | -15℃～+70℃ | -15℃～+120℃ | 1.5 | CDLA-12/WB1F14 | 41 |
| CDM1-29 | 1 | 161 | 41 | 1 | 2900 | 74.5 | 29 | -15℃～+70℃ | -15℃～+120℃ | 1.5 | CDLA-12/WB1F14 | 42 |
| CDM1-30 | 1 | 167 | 41 | 1.1 | 2900 | 74.5 | 30 | -15℃～+70℃ | -15℃～+120℃ | 1.5 | CDLA-12/WB1F14 | 46 |
| CDM1-31 | 1 | 175 | 41 | 1.1 | 2900 | 74.5 | 31 | -15℃～+70℃ | -15℃～+120℃ | 2.2 | CDLA-12/WB1F14 | 44 |
| CDM1-32 | 1 | 180 | 41 | 1.2 | 2900 | 74.5 | 32 | -15℃～+70℃ | -15℃～+120℃ | 2.2 | CDLA-12/WB1F14 | 49 |
| CDM1-33 | 1 | 186 | 41 | 1.2 | 2900 | 74.5 | 33 | -15℃～+70℃ | -15℃～+120℃ | 2.2 | CDLA-12/WB1F14 | 45 |
| CDM1-34 | 1 | 192 | 41 | 1.2 | 2900 | 74.5 | 34 | -15℃～+70℃ | -15℃～+120℃ | 2.2 | CDLA-12/WB1F16 | 46 |
| CDM1-35 | 1 | 197 | 41 | 1.3 | 2900 | 74.5 | 35 | -15℃～+70℃ | -15℃～+120℃ | 2.2 | CDLA-12/WB1F14 | 46 |
| CDM1-36 | 1 | 203 | 41 | 1.3 | 2900 | 74.5 | 36 | -15℃～+70℃ | -15℃～+120℃ | 2.2 | CDLA-12/WB1F14 | 51 |
| CDM1-37 | 1 | 209 | 41 | 1.4 | 2900 | 74.5 | 37 | -15℃～+70℃ | -15℃～+120℃ | 2.2 | CDLA-12/WB1F14 | 47 |
| CDM1-38 | 1 | 215 | 41 | 1.4 | 2900 | 74.5 | 38 | -15℃～+70℃ | -15℃～+120℃ | 2.2 | CDLA-12/WB1F14 | 51 |
| CDM1-39 | 1 | 220 | 41 | 1.4 | 2900 | 74.5 | 39 | -15℃～+70℃ | -15℃～+120℃ | 2.2 | CDLA-12/WB1F14 | 48 |
| CDM1-40 | 1 | 226 | 41 | 1.5 | 2900 | 74.5 | 40 | -15℃～+70℃ | -15℃～+120℃ | 2.2 | CDLA-12/WB1F16 | 48 |
| CDM3-2 | 3 | 11 | 58 | 0.16 | 2900 | 82 | 2 | -15℃～+70℃ | -15℃～+120℃ | 0.37 | CDLA-12/WB1F14 | 24 |
| CDM3-3 | 3 | 17 | 58 | 0.24 | 2900 | 82 | 3 | -15℃～+70℃ | -15℃～+120℃ | 0.37 | CDLA-12/WB1F14 | 24 |
| CDM3-4 | 3 | 23 | 58 | 0.32 | 2900 | 82 | 4 | -15℃～+70℃ | -15℃～+120℃ | 0.37 | CDLA-12/WB1F16 | 21 |
| CDM3-5 | 3 | 29 | 58 | 0.41 | 2900 | 82 | 5 | -15℃～+70℃ | -15℃～+120℃ | 0.55 | CDLA-12/WB1F14 | 26 |
| CDM3-6 | 3 | 35 | 58 | 0.49 | 2900 | 82 | 6 | -15℃～+70℃ | -15℃～+120℃ | 0.55 | CDLA-12/WB1F14 | 27 |
| CDM3-7 | 3 | 41 | 58 | 0.58 | 2900 | 82 | 7 | -15℃～+70℃ | -15℃～+120℃ | 0.75 | CDLA-12/WB1F14 | 30 |
| CDM3-8 | 3 | 47 | 58 | 0.66 | 2900 | 82 | 8 | -15℃～+70℃ | -15℃～+120℃ | 0.75 | CDLA-12/WB1F14 | 30 |
| CDM3-9 | 3 | 53 | 58 | 0.75 | 2900 | 82 | 9 | -15℃～+70℃ | -15℃～+120℃ | 1.1 | CDLA-12/WB1F14 | 32 |
| CDM3-10 | 3 | 59 | 58 | 0.83 | 2900 | 82 | 10 | -15℃～+70℃ | -15℃～+120℃ | 1.1 | CDLA-12/WB1F14 | 33 |
| CDM3-11 | 3 | 65 | 58 | 0.92 | 2900 | 82 | 11 | -15℃～+70℃ | -15℃～+120℃ | 1.1 | CDLA-12/WB1F14 | 33 |
| CDM3-12 | 3 | 71 | 58 | 1 | 2900 | 82 | 12 | -15℃～+70℃ | -15℃～+120℃ | 1.1 | CDLA-12/WB1F14 | 34 |
| CDM3-13 | 3 | 77 | 58 | 1.1 | 2900 | 82 | 13 | -15℃～+70℃ | -15℃～+120℃ | 1.5 | CDLA-12/WB1F14 | 39 |
| CDM3-14 | 3 | 83 | 58 | 1.2 | 2900 | 82 | 14 | -15℃～+70℃ | -15℃～+120℃ | 1.5 | CDLA-12/WB1F14 | 40 |
| CDM3-15 | 3 | 90 | 58 | 1.3 | 2900 | 82 | 15 | -15℃～+70℃ | -15℃～+120℃ | 1.5 | CDLA-12/WB1F14 | 40 |
| CDM3-16 | 3 | 96 | 58 | 1.4 | 2900 | 82 | 16 | -15℃～+70℃ | -15℃～+120℃ | 1.5 | CDLA-12/WB1F14 | 41 |
| CDM3-17 | 3 | 102 | 58 | 1.4 | 2900 | 82 | 17 | -15℃～+70℃ | -15℃～+120℃ | 2.2 | CDLA-12/WB1F16 | 38 |
| CDM3-18 | 3 | 108 | 58 | 1.5 | 2900 | 82 | 18 | -15℃～+70℃ | -15℃～+120℃ | 2.2 | CDLA-12/WB1F14 | 39 |
| CDM3-19 | 3 | 114 | 58 | 1.6 | 2900 | 82 | 19 | -15℃～+70℃ | -15℃～+120℃ | 2.2 | CDLA-12/WB1F14 | 44 |
| CDM3-20 | 3 | 120 | 58 | 1.7 | 2900 | 82 | 20 | -15℃～+70℃ | -15℃～+120℃ | 2.2 | CDLA-12/WB1F14 | 40 |
| CDM3-21 | 3 | 126 | 58 | 1.8 | 2900 | 82 | 21 | -15℃～+70℃ | -15℃～+120℃ | 2.2 | CDLA-12/WB1F16 | 41 |
| CDM3-22 | 3 | 132 | 58 | 1.9 | 2900 | 82 | 22 | -15℃～+70℃ | -15℃～+120℃ | 2.2 | CDLA-12/WB1F16 | 41 |
| CDM3-23 | 3 | 138 | 58 | 1.9 | 2900 | 82 | 23 | -15℃～+70℃ | -15℃～+120℃ | 2.2 | CDLA-12/WB1F14 | 46 |
| CDM3-24 | 3 | 144 | 58 | 2 | 2900 | 82 | 24 | -15℃～+70℃ | -15℃～+120℃ | 2.2 | CDLA-12/WB1F14 | 52 |
| CDM3-25 | 3 | 150 | 58 | 2.1 | 2900 | 82 | 25 | -15℃～+70℃ | -15℃～+120℃ | 3 | CDLA-12/WB1F14 | 57 |
| CDM3-26 | 3 | 156 | 58 | 2.2 | 2900 | 82 | 26 | -15℃～+70℃ | -15℃～+120℃ | 3 | CDLA-12/WB1F14 | 53 |
| CDM3-27 | 3 | 162 | 58 | 2.3 | 2900 | 82 | 27 | -15℃～+70℃ | -15℃～+120℃ | 3 | CDLA-12/WB1F16 | 54 |
| CDM3-28 | 3 | 168 | 58 | 2.4 | 2900 | 82 | 28 | -15℃～+70℃ | -15℃～+120℃ | 3 | CDLA-12/WB1F16 | 54 |
| CDM3-29 | 3 | 175 | 58 | 2.5 | 2900 | 82 | 29 | -15℃～+70℃ | -15℃～+120℃ | 3 | CDLA-12/WB1F14 | 58 |
| CDM3-30 | 3 | 181 | 58 | 2.4 | 2900 | 82 | 30 | -15℃～+70℃ | -15℃～+120℃ | 3 | CDLA-12/WB1F14 | 55 |
| CDM3-31 | 3 | 187 | 58 | 2.6 | 2900 | 82 | 31 | -15℃～+70℃ | -15℃～+120℃ | 3 | CDLA-12/WB1F14 | 59 |
| CDM5-2 | 5 | 11.5 | 69 | 0.22 | 2900 | 82 | 2 | -15℃～+70℃ | -15℃～+120℃ | 0.37 | CDLA-12/WB1F16 | 19 |
| CDM5-3 | 5 | 17.5 | 69 | 0.34 | 2900 | 82 | 3 | -15℃～+70℃ | -15℃～+120℃ | 0.55 | CDLA-12/WB1F14 | 26 |
| CDM5-4 | 5 | 24 | 69 | 0.47 | 2900 | 82 | 4 | -15℃～+70℃ | -15℃～+120℃ | 0.55 | CDLA-12/WB1F14 | 27 |
| CDM5-5 | 5 | 30 | 69 | 0.58 | 2900 | 82 | 5 | -15℃～+70℃ | -15℃～+120℃ | 0.75 | CDLA-12/WB1F14 | 30 |
| CDM5-6 | 5 | 37 | 69 | 0.71 | 2900 | 82 | 6 | -15℃～+70℃ | -15℃～+120℃ | 1.1 | CDLA-12/WB1F14 | 32 |
| CDM5-7 | 5 | 42.5 | 69 | 0.83 | 2900 | 82 | 7 | -15℃～+70℃ | -15℃～+120℃ | 1.1 | CDLA-12/WB1F14 | 32 |
| CDM5-8 | 5 | 49 | 69 | 0.95 | 2900 | 82 | 8 | -15℃～+70℃ | -15℃～+120℃ | 1.1 | CDLA-12/WB1F14 | 33 |
| CDM5-9 | 5 | 55 | 69 | 1.1 | 2900 | 82 | 9 | -15℃～+70℃ | -15℃～+120℃ | 1.5 | CDLA-12/WB1F14 | 38 |
| CDM5-10 | 5 | 62 | 69 | 1.2 | 2900 | 82 | 10 | -15℃～+70℃ | -15℃～+120℃ | 1.5 | CDLA-12/WB1F14 | 39 |
| CDM5-11 | 5 | 68 | 69 | 1.3 | 2900 | 82 | 11 | -15℃～+70℃ | -15℃～+120℃ | 1.5 | CDLA-12/WB1F14 | 39 |
| CDM5-12 | 5 | 74.5 | 69 | 1.4 | 2900 | 82 | 12 | -15℃～+70℃ | -15℃～+120℃ | 2.2 | CDLA-12/WB1F14 | 42 |
| CDM5-13 | 5 | 80 | 69 | 1.6 | 2900 | 82 | 13 | -15℃～+70℃ | -15℃～+120℃ | 2.2 | CDLA-12/WB1F14 | 42 |
| CDM5-14 | 5 | 87 | 69 | 1.7 | 2900 | 82 | 14 | -15℃～+70℃ | -15℃～+120℃ | 2.2 | CDLA-12/WB1F14 | 43 |
| CDM5-15 | 5 | 93 | 69 | 1.8 | 2900 | 82 | 15 | -15℃～+70℃ | -15℃～+120℃ | 2.2 | CDLA-12/WB1F14 | 43 |
| CDM5-16 | 5 | 99 | 69 | 1.9 | 2900 | 82 | 16 | -15℃～+70℃ | -15℃～+120℃ | 2.2 | CDLA-12/WB1F14 | 44 |
| CDM5-17 | 5 | 105 | 69 | 2 | 2900 | 82 | 17 | -15℃～+70℃ | -15℃～+120℃ | 3 | CDLA-12/WB1F14 | 50 |
| CDM5-18 | 5 | 111 | 69 | 2.2 | 2900 | 82 | 18 | -15℃～+70℃ | -15℃～+120℃ | 3 | CDLA-12/WB1F14 | 55 |
| CDM5-19 | 5 | 118 | 69 | 2.3 | 2900 | 82 | 19 | -15℃～+70℃ | -15℃～+120℃ | 3 | CDLA-12/WB1F14 | 51 |
| CDM5-20 | 5 | 124 | 69 | 2.4 | 2900 | 82 | 20 | -15℃～+70℃ | -15℃～+120℃ | 3 | CDLA-12/WB1F14 | 51 |
| CDM5-21 | 5 | 130 | 69 | 2.5 | 2900 | 82 | 21 | -15℃～+70℃ | -15℃～+120℃ | 3 | CDLA-12/WB1F14 | 57 |
| CDM5-22 | 5 | 136 | 69 | 2.6 | 2900 | 82 | 22 | -15℃～+70℃ | -15℃～+120℃ | 4 | CDLA-12/WB1F14 | 59 |
| CDM5-23 | 5 | 142 | 69 | 2.8 | 2900 | 82 | 23 | -15℃～+70℃ | -15℃～+120℃ | 4 | CDLA-12/WB1F16 | 60 |
| CDM5-24 | 5 | 149 | 69 | 2.9 | 2900 | 82 | 24 | -15℃～+70℃ | -15℃～+120℃ | 4 | CDLA-12/WB1F14 | 60 |
| CDM5-25 | 5 | 155 | 69 | 3 | 2900 | 82 | 25 | -15℃～+70℃ | -15℃～+120℃ | 4 | CDLA-12/WB1F14 | 66 |
| CDM5-26 | 5 | 161 | 69 | 3.1 | 2900 | 82 | 26 | -15℃～+70℃ | -15℃～+120℃ | 4 | CDLA-12/WB1F14 | 61 |
| CDM5-27 | 5 | 168 | 69 | 3.3 | 2900 | 82 | 27 | -15℃～+70℃ | -15℃～+120℃ | 4 | CDLA-12/WB1F14 | 62 |
| CDM5-28 | 5 | 174 | 69 | 3.4 | 2900 | 82 | 28 | -15℃～+70℃ | -15℃～+120℃ | 4 | CDLA-12/WB1F14 | 67 |
| CDM5-29 | 5 | 180 | 69 | 3.5 | 2900 | 82 | 29 | -15℃～+70℃ | -15℃～+120℃ | 5.5 | CDLA-12/WB1F14 | 82 |
| CDM5-30 | 5 | 186 | 69 | 3.6 | 2900 | 82 | 30 | -15℃～+70℃ | -15℃～+120℃ | 5.5 | CDLA-12/WB1F16 | 83 |
| CDM5-31 | 5 | 193 | 69 | 3.8 | 2900 | 82 | 31 | -15℃～+70℃ | -15℃～+120℃ | 5.5 | CDLA-12/WB1F14 | 83 |
| CDM5-32 | 5 | 200 | 69 | 3.9 | 2900 | 82 | 32 | -15℃～+70℃ | -15℃～+120℃ | 5.5 | CDLA-12/WB1F14 | 84 |
| CDM5-33 | 5 | 206 | 69 | 4 | 2900 | 82 | 33 | -15℃～+70℃ | -15℃～+120℃ | 5.5 | CDLA-12/WB1F14 | 89 |
| CDM10-1 | 10 | 8 | 72 | 0.3 | 2900 | 100 | 1 | -15℃～+70℃ | -15℃～+120℃ | 0.75 | CDLA-16/WB1F14 | 29 |
| CDM10-2 | 10 | 16.5 | 72 | 0.62 | 2900 | 100 | 2 | -15℃～+70℃ | -15℃～+120℃ | 0.75 | CDLA-16/WB1F14 | 30 |
| CDM10-3 | 10 | 25.5 | 72 | 0.97 | 2900 | 100 | 3 | -15℃～+70℃ | -15℃～+120℃ | 1.1 | CDLA-16/WB1F14 | 33 |
| CDM10-4 | 10 | 34 | 72 | 1.3 | 2900 | 100 | 4 | -15℃～+70℃ | -15℃～+120℃ | 1.5 | CDLA-16/WB1F14 | 39 |
| CDM10-5 | 10 | 43 | 72 | 1.6 | 2900 | 100 | 5 | -15℃～+70℃ | -15℃～+120℃ | 2.2 | CDLA-16/WB1F14 | 43 |
| CDM10-6 | 10 | 52 | 72 | 2 | 2900 | 100 | 6 | -15℃～+70℃ | -15℃～+120℃ | 2.2 | CDLA-16/WB1F14 | 44 |
| CDM10-7 | 10 | 62 | 72 | 2.4 | 2900 | 100 | 7 | -15℃～+70℃ | -15℃～+120℃ | 3 | CDLA-16/WB1F14 | 55 |
| CDM10-8 | 10 | 71 | 72 | 2.7 | 2900 | 100 | 8 | -15℃～+70℃ | -15℃～+120℃ | 3 | CDLA-16/WB1F14 | 56 |
| CDM10-9 | 10 | 80 | 72 | 3 | 2900 | 100 | 9 | -15℃～+70℃ | -15℃～+120℃ | 4 | CDLA-16/WB1F14 | 63 |
| CDM10-10 | 10 | 89 | 72 | 3.4 | 2900 | 100 | 10 | -15℃～+70℃ | -15℃～+120℃ | 4 | CDLA-16/WB1F14 | 64 |
| CDM10-11 | 10 | 98 | 72 | 3.7 | 2900 | 100 | 11 | -15℃～+70℃ | -15℃～+120℃ | 4 | CDLA-16/WB1F14 | 65 |
| CDM10-12 | 10 | 107 | 72 | 4 | 2900 | 100 | 12 | -15℃～+70℃ | -15℃～+120℃ | 4.5 | CDLA-16/WB1F14 | 66 |
| CDM10-13 | 10 | 116 | 72 | 4.4 | 2900 | 100 | 13 | -15℃～+70℃ | -15℃～+120℃ | 5.5 | CDLA-16/WB1F14 | 86 |
| CDM10-14 | 10 | 125 | 72 | 4.7 | 2900 | 100 | 14 | -15℃～+70℃ | -15℃～+120℃ | 5.5 | CDLA-16/WB1F16 | 87 |
| CDM10-15 | 10 | 134 | 72 | 5.1 | 2900 | 100 | 15 | -15℃～+70℃ | -15℃～+120℃ | 5.5 | CDLA-16/WB1F14 | 88 |
| CDM10-16 | 10 | 144 | 72 | 5.4 | 2900 | 100 | 16 | -15℃～+70℃ | -15℃～+120℃ | 7.5 | CDLA-16/WB1F14 | 97 |
| CDM10-17 | 10 | 153 | 72 | 5.8 | 2900 | 100 | 17 | -15℃～+70℃ | -15℃～+120℃ | 7.5 | CDLA-16/WB1F16 | 98 |
| CDM10-18 | 10 | 163 | 72 | 6.2 | 2900 | 100 | 18 | -15℃～+70℃ | -15℃～+120℃ | 7.5 | CDLA-16/WB1F14 | 99 |
| CDM10-19 | 10 | 172 | 72 | 6.5 | 2900 | 100 | 19 | -15℃～+70℃ | -15℃～+120℃ | 7.5 | CDLA-16/WB1F14 | 100 |
| CDM10-20 | 10 | 181 | 72 | 6.8 | 2900 | 100 | 20 | -15℃～+70℃ | -15℃～+120℃ | 7.5 | CDLA-16/WB1F16 | 101 |
| CDM10-21 | 10 | 191 | 72 | 7.2 | 2900 | 100 | 21 | -15℃～+70℃ | -15℃～+120℃ | 7.5 | CDLA-16/WB1F14 | 102 |
| CDM10-22 | 10 | 201 | 72 | 7.6 | 2900 | 100 | 22 | -15℃～+70℃ | -15℃～+120℃ | 11 | CDLA-16/WB1F14 | 168 |
| CDM15-1 | 15 | 11 | 71 | 0.63 | 2900 | 105.2 | 1 | -15℃～+70℃ | -15℃～+120℃ | 1.1 | CDLA-16/WB1F14 | 33 |
| CDM15-2 | 15 | 22.5 | 71 | 1.3 | 2900 | 105.2 | 2 | -15℃～+70℃ | -15℃～+120℃ | 2.2 | CDLA-16/WB1F14 | 41 |
| CDM15-3 | 15 | 34.5 | 71 | 2 | 2900 | 105.2 | 3 | -15℃～+70℃ | -15℃～+120℃ | 3 | CDLA-16/WB1F14 | 52 |
| CDM15-4 | 15 | 47 | 71 | 2.6 | 2900 | 105.2 | 4 | -15℃～+70℃ | -15℃～+120℃ | 4 | CDLA-16/WB1F14 | 59 |
| CDM15-5 | 15 | 58 | 71 | 3.3 | 2900 | 105.2 | 5 | -15℃～+70℃ | -15℃～+120℃ | 4 | CDLA-16/WB1F14 | 61 |
| CDM15-6 | 15 | 69 | 71 | 4 | 2900 | 105.2 | 6 | -15℃～+70℃ | -15℃～+120℃ | 5.5 | CDLA-16/WB1F14 | 83 |
| CDM15-7 | 15 | 81 | 71 | 4.7 | 2900 | 105.2 | 7 | -15℃～+70℃ | -15℃～+120℃ | 5.5 | CDLA-16/WB1F14 | 84 |
| CDM15-8 | 15 | 93 | 71 | 5.3 | 2900 | 105.2 | 8 | -15℃～+70℃ | -15℃～+120℃ | 7.5 | CDLA-16/WB1F14 | 91 |
| CDM15-9 | 15 | 106 | 71 | 6 | 2900 | 105.2 | 9 | -15℃～+70℃ | -15℃～+120℃ | 7.5 | CDLA-16/WB1F14 | 92 |
| CDM15-10 | 15 | 118 | 71 | 6.7 | 2900 | 105.2 | 10 | -15℃～+70℃ | -15℃～+120℃ | 11 | CDLA-16/WB1F14 | 150 |
| CDM15-11 | 15 | 130 | 71 | 7.4 | 2900 | 105.2 | 11 | -15℃～+70℃ | -15℃～+120℃ | 11 | CDLA-16/WB1F14 | 151 |
| CDM15-12 | 15 | 142 | 71 | 8.1 | 2900 | 105.2 | 12 | -15℃～+70℃ | -15℃～+120℃ | 11 | CDLA-16/WB1F14 | 153 |
| CDM15-13 | 15 | 152 | 71 | 8.8 | 2900 | 105.2 | 13 | -15℃～+70℃ | -15℃～+120℃ | 11 | CDLA-16/WB1F14 | 154 |
| CDM15-14 | 15 | 165 | 71 | 9.5 | 2900 | 105.2 | 14 | -15℃～+70℃ | -15℃～+120℃ | 11 | CDLA-16/WB1F14 | 156 |
| CDM15-15 | 15 | 178 | 71 | 10.2 | 2900 | 105.2 | 15 | -15℃～+70℃ | -15℃～+120℃ | 15 | CDLA-16/WB1F16 | 172 |
| CDM15-16 | 15 | 189 | 71 | 10.9 | 2900 | 105.2 | 16 | -15℃～+70℃ | -15℃～+120℃ | 15 | CDLA-16/WB1F14 | 173 |
| CDM15-17 | 15 | 201 | 71 | 11.6 | 2900 | 105.2 | 17 | -15℃～+70℃ | -15℃～+120℃ | 15 | CDLA-16/WB1F14 | 175 |
| CDM15-18 | 15 | 213 | 71 | 12.3 | 2900 | 105.2 | 18 | -15℃～+70℃ | -15℃～+120℃ | 15 | CDLA-16/WB1F14 | 184 |
| CDM20-1 | 20 | 10.5 | 72 | 0.79 | 2900 | 105.5 | 1 | -15℃～+70℃ | -15℃～+120℃ | 1.1 | CDLA-16/WB1F16 | 33 |
| CDM20-2 | 20 | 23 | 72 | 1.7 | 2900 | 105.5 | 2 | -15℃～+70℃ | -15℃～+120℃ | 2.2 | CDLA-16/WB1F14 | 41 |
| CDM20-3 | 20 | 35 | 72 | 2.6 | 2900 | 105.5 | 3 | -15℃～+70℃ | -15℃～+120℃ | 4 | CDLA-16/WB1F14 | 59 |
| CDM20-4 | 20 | 47 | 72 | 3.5 | 2900 | 105.5 | 4 | -15℃～+70℃ | -15℃～+120℃ | 5.5 | CDLA-16/WB1F14 | 81 |
| CDM20-5 | 20 | 58 | 72 | 4.4 | 2900 | 105.5 | 5 | -15℃～+70℃ | -15℃～+120℃ | 5.5 | CDLA-16/WB1F14 | 83 |
| CDM20-6 | 20 | 70 | 72 | 5.3 | 2900 | 105.5 | 6 | -15℃～+70℃ | -15℃～+120℃ | 7.5 | CDLA-16/WB1F14 | 92 |
| CDM20-7 | 20 | 82 | 72 | 6.2 | 2900 | 105.5 | 7 | -15℃～+70℃ | -15℃～+120℃ | 7.5 | CDLA-16/WB1F14 | 93 |
| CDM20-8 | 20 | 95 | 72 | 7.2 | 2900 | 105.5 | 8 | -15℃～+70℃ | -15℃～+120℃ | 11 | CDLA-16/WB1F14 | 160 |
| CDM20-9 | 20 | 107 | 72 | 8.1 | 2900 | 105.5 | 9 | -15℃～+70℃ | -15℃～+120℃ | 11 | CDLA-16/WB1F14 | 161 |
| CDM20-10 | 20 | 119 | 72 | 9 | 2900 | 105.5 | 10 | -15℃～+70℃ | -15℃～+120℃ | 11 | CDLA-16/WB1F14 | 163 |
| CDM20-11 | 20 | 131 | 72 | 9.9 | 2900 | 105.5 | 11 | -15℃～+70℃ | -15℃～+120℃ | 15 | CDLA-16/WB1F14 | 180 |
| CDM20-12 | 20 | 143 | 72 | 10.8 | 2900 | 105.5 | 12 | -15℃～+70℃ | -15℃～+120℃ | 15 | CDLA-16/WB1F14 | 181 |
| CDM20-13 | 20 | 155 | 72 | 11.7 | 2900 | 105.5 | 13 | -15℃～+70℃ | -15℃～+120℃ | 15 | CDLA-16/WB1F14 | 182 |
| CDM20-14 | 20 | 168 | 72 | 12.7 | 2900 | 105.5 | 14 | -15℃～+70℃ | -15℃～+120℃ | 15 | CDLA-16/WB1F14 | 184 |
| CDM20-15 | 20 | 180 | 72 | 13.6 | 2900 | 105.5 | 15 | -15℃～+70℃ | -15℃～+120℃ | 18.5 | CDLA-16/WB1F14 | 202 |
| CDM20-16 | 20 | 193 | 72 | 14.6 | 2900 | 105.5 | 16 | -15℃～+70℃ | -15℃～+120℃ | 18.5 | CDLA-16/WB1F14 | 203 |
| CDM20-17 | 20 | 205 | 72 | 15.5 | 2900 | 105.5 | 17 | -15℃～+70℃ | -15℃～+120℃ | 18.5 | CDLA-16/WB1F14 | 205 |
| CDM32-1-1 | 32 | 9 | 68.5 | 1.1 | 2900 | 118.2 | 1 | -15℃～+70℃ | -15℃～+120℃ | 1.5 | CDLA-22/WB1F16 | 64 |
| CDM32-1 | 32 | 13 | 68.5 | 1.7 | 2900 | 118.2 | 1 | -15℃～+70℃ | -15℃～+120℃ | 2.2 | CDLA-22/WB1F16 | 68 |
| CDM32-2-2 | 32 | 20 | 68.5 | 2.6 | 2900 | 118.2 | 2 | -15℃～+70℃ | -15℃～+120℃ | 3 | CDLA-22/WB1F16 | 77 |
| CDM32-2 | 32 | 27 | 68.5 | 3.5 | 2900 | 118.2 | 2 | -15℃～+70℃ | -15℃～+120℃ | 4 | CDLA-22/WB1F16 | 85 |
| CDM32-3-2 | 32 | 33 | 68.5 | 4.2 | 2900 | 118.2 | 3 | -15℃～+70℃ | -15℃～+120℃ | 5.5 | CDLA-22/WB1F16 | 100 |
| CDM32-3 | 32 | 40 | 68.5 | 5.1 | 2900 | 118.2 | 3 | -15℃～+70℃ | -15℃～+120℃ | 5.5 | CDLA-22/WB1F16 | 100 |
| CDM32-4-2 | 32 | 46 | 68.5 | 5.9 | 2900 | 118.2 | 4 | -15℃～+70℃ | -15℃～+120℃ | 7.5 | CDM-22/WB1F14 | 109 |
| CDM32-4 | 32 | 53 | 68.5 | 6.8 | 2900 | 118.2 | 4 | -15℃～+70℃ | -15℃～+120℃ | 7.5 | CDLA-22/WB1F16 | 109 |
| CDM32-5-2 | 32 | 60 | 68.5 | 7.7 | 2900 | 118.2 | 5 | -15℃～+70℃ | -15℃～+120℃ | 11 | CDLA-22/WB1F16 | 181 |
| CDM32-5 | 32 | 67 | 68.5 | 8.6 | 2900 | 118.2 | 5 | -15℃～+70℃ | -15℃～+120℃ | 11 | CDM-22/WB1F14 | 181 |
| CDM32-6-2 | 32 | 74 | 68.5 | 9.5 | 2900 | 118.2 | 6 | -15℃～+70℃ | -15℃～+120℃ | 11 | CDLA-22/WB1F16 | 185 |
| CDM32-6 | 32 | 81 | 68.5 | 10.4 | 2900 | 118.2 | 6 | -15℃～+70℃ | -15℃～+120℃ | 11 | CDLA-22/WB1F16 | 185 |
| CDM32-7-2 | 32 | 88 | 68.5 | 11.3 | 2900 | 118.2 | 7 | -15℃～+70℃ | -15℃～+120℃ | 15 | CDM-22/WB1F14 | 199 |
| CDM32-7 | 32 | 95 | 68.5 | 12.2 | 2900 | 118.2 | 7 | -15℃～+70℃ | -15℃～+120℃ | 15 | CDLA-22/WB1F16 | 199 |
| CDM32-8-2 | 32 | 102 | 68.5 | 13 | 2900 | 118.2 | 8 | -15℃～+70℃ | -15℃～+120℃ | 15 | CDLA-22/WB1F16 | 203 |
| CDM32-8 | 32 | 109 | 68.5 | 13.9 | 2900 | 118.2 | 8 | -15℃～+70℃ | -15℃～+120℃ | 15 | CDLA-22/WB1F16 | 203 |
| CDM32-9-2 | 32 | 117 | 68.5 | 15 | 2900 | 118.2 | 9 | -15℃～+70℃ | -15℃～+120℃ | 18.5 | CDLA-22/WB1F16 | 222 |
| CDM32-9 | 32 | 124 | 68.5 | 15.8 | 2900 | 118.2 | 9 | -15℃～+70℃ | -15℃～+120℃ | 18.5 | CDLA-22/WB1F16 | 222 |
| CDM32-10-2 | 32 | 131 | 68.5 | 16.8 | 2900 | 118.2 | 10 | -15℃～+70℃ | -15℃～+120℃ | 18.5 | CDLA-22/WB1F16 | 227 |
| CDM32-10 | 32 | 138 | 68.5 | 17.6 | 2900 | 118.2 | 10 | -15℃～+70℃ | -15℃～+120℃ | 18.5 | CDLA-22/WB1F16 | 227 |
| CDM32-11-2 | 32 | 146 | 68.5 | 18.7 | 2900 | 118.2 | 11 | -15℃～+70℃ | -15℃～+120℃ | 22 | CDLA-22/WB1F16 | 272 |
| CDM32-11 | 32 | 153 | 68.5 | 19.6 | 2900 | 118.2 | 11 | -15℃～+70℃ | -15℃～+120℃ | 22 | CDLA-22/WB1F16 | 272 |
| CDM32-12-2 | 32 | 160 | 68.5 | 20.5 | 2900 | 118.2 | 12 | -15℃～+70℃ | -15℃～+120℃ | 22 | CDLA-22/WB1F16 | 276 |
| CDM32-12 | 32 | 167 | 68.5 | 21.4 | 2900 | 118.2 | 12 | -15℃～+70℃ | -15℃～+120℃ | 22 | CDLA-22/WB1F16 | 276 |
| CDM32-13-2 | 32 | 174 | 68.5 | 22.3 | 2900 | 118.2 | 13 | -15℃～+70℃ | -15℃～+120℃ | 30 | CDLA-22/WB1F16 | 337 |
| CDM32-13 | 32 | 181 | 68.5 | 23.1 | 2900 | 118.2 | 13 | -15℃～+70℃ | -15℃～+120℃ | 30 | CDLA-22/WB1F16 | 337 |
| CDM32-14-2 | 32 | 189 | 68.5 | 24.2 | 2900 | 118.2 | 14 | -15℃～+70℃ | -15℃～+120℃ | 30 | CDM-22/WB1F14 | 341 |
| CDM32-14 | 32 | 196 | 68.5 | 25 | 2900 | 118.2 | 14 | -15℃～+70℃ | -15℃～+120℃ | 30 | CDLA-22/WB1F16 | 341 |
| CDM32-15-2 | 32 | 203 | 68.5 | 26 | 2900 | 118.2 | 15 | -15℃～+70℃ | -15℃～+120℃ | 30 | CDLA-22/WB1F16 | 345 |
| CDM32-15 | 32 | 210 | 68.5 | 26.9 | 2900 | 118.2 | 15 | -15℃～+70℃ | -15℃～+120℃ | 30 | CDM-22/WB1F14 | 345 |
| CDM32-16-2 | 32 | 218 | 68.5 | 27.9 | 2900 | 118.2 | 16 | -15℃～+70℃ | -15℃～+120℃ | 30 | CDLA-22/WB1F16 | 350 |
| CDM32-16 | 32 | 225 | 68.5 | 28.8 | 2900 | 118.2 | 16 | -15℃～+70℃ | -15℃～+120℃ | 30 | CDLA-22/WB1F16 | 350 |
| CDM42-1-1 | 42 | 16 | 69.8 | 2.6 | 2900 | 136 | 1 | -15℃～+70℃ | -15℃～+120℃ | 3 | CDM-22/WB1F14 | 83 |
| CDM42-1 | 42 | 20 | 69.8 | 3.3 | 2900 | 136 | 1 | -15℃～+70℃ | -15℃～+120℃ | 4 | CDLA-22/WB1F16 | 90 |
| CDM42-2-2 | 42 | 32 | 69.8 | 5.3 | 2900 | 136 | 2 | -15℃～+70℃ | -15℃～+120℃ | 5.5 | CDLA-22/WB1F16 | 105 |
| CDM42-2 | 42 | 41 | 69.8 | 6.7 | 2900 | 136 | 2 | -15℃～+70℃ | -15℃～+120℃ | 7.5 | CDLA-22/WB1F16 | 110 |
| CDM42-3-2 | 42 | 52 | 69.8 | 8.5 | 2900 | 136 | 3 | -15℃～+70℃ | -15℃～+120℃ | 11 | CDLA-22/WB1F16 | 183 |
| CDM42-3 | 42 | 61 | 69.8 | 10 | 2900 | 136 | 3 | -15℃～+70℃ | -15℃～+120℃ | 11 | CDLA-22/WB1F16 | 183 |
| CDM42-4-2 | 42 | 73 | 69.8 | 12 | 2900 | 136 | 4 | -15℃～+70℃ | -15℃～+120℃ | 15 | CDLA-22/WB1F16 | 197 |
| CDM42-4 | 42 | 81 | 69.8 | 13.3 | 2900 | 136 | 4 | -15℃～+70℃ | -15℃～+120℃ | 15 | CDLA-22/WB1F16 | 197 |
| CDM42-5-2 | 42 | 93 | 69.8 | 15.3 | 2900 | 136 | 5 | -15℃～+70℃ | -15℃～+120℃ | 18.5 | CDLA-22/WB1F16 | 221 |
| CDM42-5 | 42 | 101 | 69.8 | 16.6 | 2900 | 136 | 5 | -15℃～+70℃ | -15℃～+120℃ | 18.5 | CDLA-22/WB1F16 | 221 |
| CDM42-6-2 | 42 | 113 | 69.8 | 18.5 | 2900 | 136 | 6 | -15℃～+70℃ | -15℃～+120℃ | 22 | CDLA-22/WB1F16 | 261 |
| CDM42-6 | 42 | 122 | 69.8 | 20 | 2900 | 136 | 6 | -15℃～+70℃ | -15℃～+120℃ | 22 | CDLA-22/WB1F16 | 261 |
| CDM42-7-2 | 42 | 134 | 69.8 | 22 | 2900 | 136 | 7 | -15℃～+70℃ | -15℃～+120℃ | 30 | CDLA-22/WB1F16 | 320 |
| CDM42-7 | 42 | 142 | 69.8 | 23.3 | 2900 | 136 | 7 | -15℃～+70℃ | -15℃～+120℃ | 30 | CDLA-22/WB1F16 | 320 |
| CDM42-8-2 | 42 | 154 | 69.8 | 25.3 | 2900 | 136 | 8 | -15℃～+70℃ | -15℃～+120℃ | 30 | CDLA-22/WB1F16 | 324 |
| CDM42-8 | 42 | 162 | 69.8 | 26.6 | 2900 | 136 | 8 | -15℃～+70℃ | -15℃～+120℃ | 30 | CDLA-22/WB1F16 | 324 |
| CDM42-9-2 | 42 | 174 | 69.8 | 28.5 | 2900 | 136 | 9 | -15℃～+70℃ | -15℃～+120℃ | 30 | CDLA-22/WB1F16 | 328 |
| CDM42-9 | 42 | 183 | 69.8 | 30 | 2900 | 136 | 9 | -15℃～+70℃ | -15℃～+120℃ | 37 | CDM-22/WB1F14 | 352 |
| CDM42-10-2 | 42 | 194 | 69.8 | 31.8 | 2900 | 136 | 10 | -15℃～+70℃ | -15℃～+120℃ | 37 | CDLA-22/WB1F16 | 355 |
| CDM42-10 | 42 | 203 | 69.8 | 33.3 | 2900 | 136 | 10 | -15℃～+70℃ | -15℃～+120℃ | 37 | CDLA-22/WB1F16 | 355 |
| CDM42-11-2 | 42 | 217 | 69.8 | 35.6 | 2900 | 136 | 11 | -15℃～+70℃ | -15℃～+120℃ | 45 | CDM-22/WB1F14 | 426 |
| CDM42-11 | 42 | 225 | 69.8 | 36.9 | 2900 | 136 | 11 | -15℃～+70℃ | -15℃～+120℃ | 45 | CDLA-22/WB1F16 | 426 |
| CDM42-12-2 | 42 | 238 | 69.8 | 39 | 2900 | 136 | 12 | -15℃～+70℃ | -15℃～+120℃ | 45 | CDLA-22/WB1F16 | 432 |
| CDM42-12 | 42 | 247 | 69.8 | 40.5 | 2900 | 136 | 12 | -15℃～+70℃ | -15℃～+120℃ | 45 | CDLA-22/WB1F16 | 432 |
| CDM42-13-2 | 42 | 259 | 69.8 | 42.5 | 2900 | 136 | 13 | -15℃～+70℃ | -15℃～+120℃ | 45 | CDLA-22/WB1F16 | 438 |
| CDM65-1-1 | 65 | 13 | 72.3 | 3.2 | 2900 | 142 | 1 | -15℃～+70℃ | -15℃～+120℃ | 4 | CDLA-22/WB1F16 | 93 |
| CDM65-1 | 65 | 20 | 72.3 | 4.9 | 2900 | 142 | 1 | -15℃～+70℃ | -15℃～+120℃ | 5.5 | CDLA-22/WB1F16 | 105 |
| CDM65-2-2 | 65 | 26 | 72.3 | 6.4 | 2900 | 142 | 2 | -15℃～+70℃ | -15℃～+120℃ | 7.5 | CDLA-22/WB1F16 | 110 |
| CDM65-2-1 | 65 | 33 | 72.3 | 8.1 | 2900 | 142 | 2 | -15℃～+70℃ | -15℃～+120℃ | 11 | CDLA-22/WB1F16 | 182 |
| CDM65-2 | 65 | 40 | 72.3 | 9.8 | 2900 | 142 | 2 | -15℃～+70℃ | -15℃～+120℃ | 11 | CDLA-22/WB1F16 | 182 |
| CDM65-3-2 | 65 | 46 | 72.3 | 11.3 | 2900 | 142 | 3 | -15℃～+70℃ | -15℃～+120℃ | 15 | CDLA-22/WB1F16 | 196 |
| CDM65-3-1 | 65 | 53 | 72.3 | 13 | 2900 | 142 | 3 | -15℃～+70℃ | -15℃～+120℃ | 15 | CDLA-22/WB1F16 | 197 |
| CDM65-3 | 65 | 60 | 72.3 | 14.7 | 2900 | 142 | 3 | -15℃～+70℃ | -15℃～+120℃ | 18.5 | CDLA-22/WB1F16 | 221 |
| CDM65-4-2 | 65 | 66 | 72.3 | 16.2 | 2900 | 142 | 4 | -15℃～+70℃ | -15℃～+120℃ | 18.5 | CDLA-22/WB1F16 | 225 |
| CDM65-4-1 | 65 | 73 | 72.3 | 17.9 | 2900 | 142 | 4 | -15℃～+70℃ | -15℃～+120℃ | 22 | CDLA-22/WB1F16 | 258 |
| CDM65-4 | 65 | 80 | 72.3 | 19.6 | 2900 | 142 | 4 | -15℃～+70℃ | -15℃～+120℃ | 22 | CDLA-22/WB1F16 | 258 |
| CDM65-5-2 | 65 | 88 | 72.3 | 21.6 | 2900 | 142 | 5 | -15℃～+70℃ | -15℃～+120℃ | 30 | CDLA-22/WB1F16 | 319 |
| CDM65-5-1 | 65 | 95 | 72.3 | 23.3 | 2900 | 142 | 5 | -15℃～+70℃ | -15℃～+120℃ | 30 | CDM-22/WB1F14 | 319 |
| CDM65-5 | 65 | 102 | 72.3 | 25 | 2900 | 142 | 5 | -15℃～+70℃ | -15℃～+120℃ | 30 | CDLA-22/WB1F16 | 320 |
| CDM65-6-2 | 65 | 110 | 72.3 | 27 | 2900 | 142 | 6 | -15℃～+70℃ | -15℃～+120℃ | 30 | CDLA-22/WB1F16 | 325 |
| CDM65-6-1 | 65 | 117 | 72.3 | 28.7 | 2900 | 142 | 6 | -15℃～+70℃ | -15℃～+120℃ | 37 | CDM-22/WB1F14 | 349 |
| CDM65-6 | 65 | 124 | 72.3 | 30.4 | 2900 | 142 | 6 | -15℃～+70℃ | -15℃～+120℃ | 37 | CDLA-22/WB1F16 | 349 |
| CDM65-7-2 | 65 | 132 | 72.3 | 32.3 | 2900 | 142 | 7 | -15℃～+70℃ | -15℃～+120℃ | 37 | CDLA-22/WB1F16 | 353 |
| CDM65-7-1 | 65 | 139 | 72.3 | 34 | 2900 | 142 | 7 | -15℃～+70℃ | -15℃～+120℃ | 37 | CDLA-22/WB1F16 | 353 |
| CDM65-7 | 65 | 146 | 72.3 | 35.8 | 2900 | 142 | 7 | -15℃～+70℃ | -15℃～+120℃ | 45 | CDLA-22/WB1F16 | 420 |
| CDM65-8-2 | 65 | 154 | 72.3 | 37.7 | 2900 | 142 | 8 | -15℃～+70℃ | -15℃～+120℃ | 45 | CDLA-22/WB1F16 | 424 |
| CDM65-8-1 | 65 | 161 | 72.3 | 39.4 | 2900 | 142 | 8 | -15℃～+70℃ | -15℃～+120℃ | 45 | CDLA-22/WB1F16 | 424 |
| CDM85-1-1 | 85 | 14 | 73.9 | 4.4 | 2900 | 145.3 | 1 | -15℃～+70℃ | -15℃～+120℃ | 5.5 | CDLA-22/WB1F16 | 105 |
| CDM85-1 | 85 | 20 | 73.9 | 6.3 | 2900 | 146 | 1 | -15℃～+70℃ | -15℃～+120℃ | 7.5 | CDLA-22/WB1F16 | 110 |
| CDM85-2-2 | 85 | 30 | 73.9 | 9.4 | 2900 | 145.3 | 2 | -15℃～+70℃ | -15℃～+120℃ | 11 | CDLA-22/WB1F16 | 181 |
| CDM85-2 | 85 | 41 | 73.9 | 12.8 | 2900 | 146 | 2 | -15℃～+70℃ | -15℃～+120℃ | 15 | CDLA-22/WB1F16 | 192 |
| CDM85-3-2 | 85 | 52 | 73.9 | 16.3 | 2900 | 146 | 3 | -15℃～+70℃ | -15℃～+120℃ | 18.5 | CDLA-22/WB1F16 | 215 |
| CDM85-3 | 85 | 64 | 73.9 | 20 | 2900 | 146 | 3 | -15℃～+70℃ | -15℃～+120℃ | 22 | CDLA-22/WB1F16 | 252 |
| CDM85-4-2 | 85 | 75 | 73.9 | 23.5 | 2900 | 146 | 4 | -15℃～+70℃ | -15℃～+120℃ | 30 | CDLA-22/WB1F16 | 312 |
| CDM85-4 | 85 | 86 | 73.9 | 27 | 2900 | 146 | 4 | -15℃～+70℃ | -15℃～+120℃ | 30 | CDLA-22/WB1F16 | 312 |
| CDM85-5-2 | 85 | 98 | 73.9 | 30.7 | 2900 | 146 | 5 | -15℃～+70℃ | -15℃～+120℃ | 37 | CDLA-22/WB1F16 | 336 |
| CDM85-5 | 85 | 110 | 73.9 | 34.5 | 2900 | 146 | 5 | -15℃～+70℃ | -15℃～+120℃ | 37 | CDLA-22/WB1F16 | 336 |
| CDM85-6-2 | 85 | 122 | 73.9 | 38.2 | 2900 | 146 | 6 | -15℃～+70℃ | -15℃～+120℃ | 45 | CDM-22/WB1F14 | 407 |
| CDM85-6 | 85 | 134 | 73.9 | 42 | 2900 | 146 | 6 | -15℃～+70℃ | -15℃～+120℃ | 45 | CDLA-22/WB1F16 | 407 |
| CDM95-1-1 | 95 | 15.5 | 73.3 | 5.5 | 2950 | 138 | 1 | -15℃～+70℃ | -15℃～+120℃ | 5.5 | CDM-22/WB1F14 | 134 |
| CDM95-1 | 95 | 22 | 78.3 | 7.3 | 2950 | 153.5 | 1 | -15℃～+70℃ | -15℃～+120℃ | 7.5 | CDM-22/WB1F14 | 142 |
| CDM95-2-2 | 95 | 31 | 74.1 | 10.8 | 2950 | 138 | 2 | -15℃～+70℃ | -15℃～+120℃ | 11 | CDM-22/WB1F14 | 218 |
| CDM95-2 | 95 | 45 | 80.4 | 14.5 | 2950 | 153.5 | 2 | -15℃～+70℃ | -15℃～+120℃ | 15 | CDM-22/WB1F14 | 233 |
| CDM95-3-2 | 95 | 54 | 77.2 | 18.1 | 2950 | 153.5 | 3 | -15℃～+70℃ | -15℃～+120℃ | 18.5 | CDM-22/WB1F14 | 246 |
| CDM95-3 | 95 | 68 | 81 | 21.7 | 2950 | 153.5 | 3 | -15℃～+70℃ | -15℃～+120℃ | 22 | CDM-22/WB1F14 | 300 |
| CDM95-4 | 95 | 91 | 81.4 | 29 | 2950 | 153.5 | 4 | -15℃～+70℃ | -15℃～+120℃ | 30 | CDM-22/WB1F14 | 367 |
| CDM95-5 | 95 | 114 | 81.6 | 36.2 | 2950 | 153.5 | 5 | -15℃～+70℃ | -15℃～+120℃ | 37 | CDM-22/WB1F14 | 392 |
| CDM95-6 | 95 | 137 | 81.7 | 43.4 | 2950 | 153.5 | 6 | -15℃～+70℃ | -15℃～+120℃ | 45 | CDM-22/WB1F14 | 497 |
| CDM95-7 | 95 | 160 | 81.8 | 50.6 | 2950 | 153.5 | 7 | -15℃～+70℃ | -15℃～+120℃ | 55 | CDM-22/WB1F14 | 567 |
| CDM95-8-2 | 95 | 167 | 80.3 | 53.8 | 2950 | 153.5 | 8 | -15℃～+70℃ | -15℃～+120℃ | 55 | CDM-22/WB1F14 | 572 |
| CDM120-1 | 120 | 18.5 | 74.7 | 8.1 | 2950 | 143.7 | 1 | -15℃～+70℃ | -15℃～+120℃ | 11 | CDLA-32/WB1F16 | 230 |
| CDM120-2-2 | 120 | 28.5 | 74.7 | 12.5 | 2950 | 132 | 2 | -15℃～+70℃ | -15℃～+120℃ | 15 | CDM-32/WB1F14 | 245 |
| CDM120-2-1 | 120 | 34.5 | 74.7 | 15.1 | 2950 | 143.7 | 2 | -15℃～+70℃ | -15℃～+120℃ | 18.5 | CDLA-32/WB1F16 | 250 |
| CDM120-2 | 120 | 40 | 74.7 | 17.5 | 2950 | 143.7 | 2 | -15℃～+70℃ | -15℃～+120℃ | 22 | CDLA-32/WB1F16 | 285 |
| CDM120-3-2 | 120 | 49 | 74.7 | 21.4 | 2950 | 143.7 | 3 | -15℃～+70℃ | -15℃～+120℃ | 30 | CDM-32/WB1F14 | 360 |
| CDM120-3-1 | 120 | 55.5 | 74.7 | 24.3 | 2950 | 143.7 | 3 | -15℃～+70℃ | -15℃～+120℃ | 30 | CDLA-32/WB1F16 | 360 |
| CDM120-3 | 120 | 61 | 74.7 | 26.7 | 2950 | 143.7 | 3 | -15℃～+70℃ | -15℃～+120℃ | 30 | CDLA-32/WB1F16 | 360 |
| CDM120-4-2 | 120 | 69 | 74.7 | 30.2 | 2950 | 143.7 | 4 | -15℃～+70℃ | -15℃～+120℃ | 37 | CDLA-32/WB1F16 | 400 |
| CDM120-4-1 | 120 | 76 | 74.7 | 33.3 | 2950 | 143.7 | 4 | -15℃～+70℃ | -15℃～+120℃ | 37 | CDLA-32/WB1F16 | 400 |
| CDM120-4 | 120 | 81 | 74.7 | 35.5 | 2950 | 143.7 | 4 | -15℃～+70℃ | -15℃～+120℃ | 45 | CDLA-32/WB1F16 | 460 |
| CDM120-5-2 | 120 | 90 | 74.7 | 39.4 | 2950 | 143.7 | 5 | -15℃～+70℃ | -15℃～+120℃ | 45 | CDLA-32/WB1F16 | 470 |
| CDM120-5-1 | 120 | 97 | 74.7 | 42.5 | 2950 | 143.7 | 5 | -15℃～+70℃ | -15℃～+120℃ | 45 | CDLA-32/WB1F16 | 470 |
| CDM120-5 | 120 | 101.5 | 74.7 | 44.4 | 2950 | 143.7 | 5 | -15℃～+70℃ | -15℃～+120℃ | 55 | CDLA-32/WB1F16 | 575 |
| CDM120-6-2 | 120 | 110 | 74.7 | 48.1 | 2950 | 143.7 | 6 | -15℃～+70℃ | -15℃～+120℃ | 55 | CDLA-32/WB1F16 | 585 |
| CDM120-6-1 | 120 | 118 | 74.7 | 51.6 | 2950 | 143.7 | 6 | -15℃～+70℃ | -15℃～+120℃ | 55 | CDLA-32/WB1F16 | 585 |
| CDM120-6 | 120 | 123 | 74.7 | 53.8 | 2950 | 143.7 | 6 | -15℃～+70℃ | -15℃～+120℃ | 75 | CDLA-32/WB1F16 | 705 |
| CDM120-7-2 | 120 | 130 | 74.7 | 57 | 2950 | 143.7 | 7 | -15℃～+70℃ | -15℃～+120℃ | 75 | CDLA-32/WB1F16 | 715 |
| CDM120-7-1 | 120 | 137.5 | 74.7 | 60.2 | 2950 | 143.7 | 7 | -15℃～+70℃ | -15℃～+120℃ | 75 | CDLA-32/WB1F16 | 715 |
| CDM120-7 | 120 | 145 | 74.7 | 63.5 | 2950 | 143.7 | 7 | -15℃～+70℃ | -15℃～+120℃ | 75 | CDM-32/WB1F14 | 715 |
| CDM150-1-1 | 150 | 12.5 | 75.8 | 6.7 | 2950 | 139 | 1 | -15℃～+70℃ | -15℃～+120℃ | 11 | CDLA-32/WB1F16 | 230 |
| CDM150-1 | 150 | 18.5 | 75.8 | 10 | 2950 | 151.5 | 1 | -15℃～+70℃ | -15℃～+120℃ | 15 | CDLA-32/WB1F16 | 235 |
| CDM150-2-2 | 150 | 27.5 | 75.8 | 14.8 | 2950 | 139 | 2 | -15℃～+70℃ | -15℃～+120℃ | 18.5 | CDM-32/WB1F14 | 250 |
| CDM150-2-1 | 150 | 35 | 75.8 | 18.9 | 2950 | 151.5 | 2 | -15℃～+70℃ | -15℃～+120℃ | 22 | CDLA-32/WB1F16 | 295 |
| CDM150-2 | 150 | 40 | 75.8 | 21.6 | 2950 | 151.5 | 2 | -15℃～+70℃ | -15℃～+120℃ | 30 | CDLA-32/WB1F16 | 350 |
| CDM150-3-2 | 150 | 49 | 75.8 | 26.4 | 2950 | 151.5 | 3 | -15℃～+70℃ | -15℃～+120℃ | 30 | CDM-32/WB1F14 | 360 |
| CDM150-3-1 | 150 | 56 | 75.8 | 30.2 | 2950 | 151.5 | 3 | -15℃～+70℃ | -15℃～+120℃ | 37 | CDLA-32/WB1F16 | 360 |
| CDM150-3 | 150 | 63 | 75.8 | 34 | 2950 | 151.5 | 3 | -15℃～+70℃ | -15℃～+120℃ | 37 | CDLA-32/WB1F16 | 385 |
| CDM150-4-2 | 150 | 70.5 | 75.8 | 38 | 2950 | 151.5 | 4 | -15℃～+70℃ | -15℃～+120℃ | 45 | CDLA-32/WB1F16 | 460 |
| CDM150-4-1 | 150 | 77 | 75.8 | 41.5 | 2950 | 151.5 | 4 | -15℃～+70℃ | -15℃～+120℃ | 45 | CDLA-32/WB1F16 | 460 |
| CDM150-4 | 150 | 84 | 75.8 | 45.3 | 2950 | 151.5 | 4 | -15℃～+70℃ | -15℃～+120℃ | 55 | CDLA-32/WB1F16 | 560 |
| CDM150-5-2 | 150 | 92 | 75.8 | 49.6 | 2950 | 151.5 | 5 | -15℃～+70℃ | -15℃～+120℃ | 55 | CDLA-32/WB1F16 | 570 |
| CDM150-5-1 | 150 | 99 | 75.8 | 53.4 | 2950 | 151.5 | 5 | -15℃～+70℃ | -15℃～+120℃ | 75 | CDLA-32/WB1F16 | 690 |
| CDM150-5 | 150 | 106.5 | 75.8 | 57.4 | 2950 | 151.5 | 5 | -15℃～+70℃ | -15℃～+120℃ | 75 | CDLA-32/WB1F16 | 690 |
| CDM150-6-2 | 150 | 112 | 75.8 | 60.4 | 2950 | 151.5 | 6 | -15℃～+70℃ | -15℃～+120℃ | 75 | CDLA-32/WB1F16 | 700 |
| CDM150-6-1 | 150 | 120.5 | 75.8 | 65 | 2950 | 151.5 | 6 | -15℃～+70℃ | -15℃～+120℃ | 75 | CDLA-32/WB1F16 | 700 |
| CDM150-6 | 150 | 130 | 75.8 | 70 | 2950 | 151.5 | 6 | -15℃～+70℃ | -15℃～+120℃ | 75 | CDLA-32/WB1F16 | 700 |
| CDM200-1-B | 200 | 20 | 77.9 | 13.5 | 2950 | 167.568 | 1 | -15℃～+70℃ | -15℃～+120℃ | 18.5 | CDLA-36/WB1F16 | 311 |
| CDM200-1-A | 200 | 24 | 77.9 | 16.2 | 2950 | 173.851 | 1 | -15℃～+70℃ | -15℃～+120℃ | 22 | CDLA-36/WB1F16 | 347 |
| CDM200-1 | 200 | 34 | 77.9 | 23 | 2950 | 188.567 | 1 | -15℃～+70℃ | -15℃～+120℃ | 30 | CDLA-36/WB1F16 | 403 |
| CDM200-2-2B | 200 | 41 | 77.9 | 27.6 | 2950 | 167.568 | 2 | -15℃～+70℃ | -15℃～+120℃ | 37 | CDLA-36/WB1F16 | 447 |
| CDM200-2-2A | 200 | 49 | 77.9 | 33 | 2950 | 173.851 | 2 | -15℃～+70℃ | -15℃～+120℃ | 45 | CDLA-36/WB1F16 | 504 |
| CDM200-2-A | 200 | 59 | 77.9 | 39.8 | 2950 | 188.567 | 2 | -15℃～+70℃ | -15℃～+120℃ | 55 | CDLA-36/WB1F16 | 595 |
| CDM200-2 | 200 | 69 | 77.9 | 46.5 | 2950 | 188.567 | 2 | -15℃～+70℃ | -15℃～+120℃ | 55 | CDLA-36/WB1F16 | 595 |
| CDM200-3-2B | 200 | 75 | 77.9 | 50.6 | 2950 | 188.567 | 3 | -15℃～+70℃ | -15℃～+120℃ | 75 | CDLA-36/WB1F16 | 748 |
| CDM200-3-A-B | 200 | 79 | 77.9 | 53.3 | 2950 | 188.567 | 3 | -15℃～+70℃ | -15℃～+120℃ | 75 | CDLA-36/WB1F16 | 748 |
| CDM200-3-2A | 200 | 84 | 77.9 | 56.7 | 2950 | 188.567 | 3 | -15℃～+70℃ | -15℃～+120℃ | 75 | CDLA-36/WB1F16 | 748 |
| CDM200-3-B | 200 | 89 | 77.9 | 60 | 2950 | 188.567 | 3 | -15℃～+70℃ | -15℃～+120℃ | 75 | CDLA-36/WB1F16 | 748 |
| CDM200-3-A | 200 | 93 | 77.9 | 62.7 | 2950 | 188.567 | 3 | -15℃～+70℃ | -15℃～+120℃ | 75 | CDLA-36/WB1F16 | 748 |
| CDM200-3 | 200 | 103 | 77.9 | 69.5 | 2950 | 188.567 | 3 | -15℃～+70℃ | -15℃～+120℃ | 90 | CDLA-36/WB1F16 | 817 |
| CDM200-4-2B | 200 | 110 | 77.9 | 74.2 | 2950 | 188.567 | 4 | -15℃～+70℃ | -15℃～+120℃ | 90 | CDLA-36/WB1F16 | 830 |
| CDM200-4-2A | 200 | 118 | 77.9 | 79.6 | 2950 | 188.567 | 4 | -15℃～+70℃ | -15℃～+120℃ | 110 | CDLA-36/WB1F16 | 1180 |
| CDM200-4-A | 200 | 128 | 77.9 | 86.3 | 2950 | 188.567 | 4 | -15℃～+70℃ | -15℃～+120℃ | 110 | CDLA-36/WB1F16 | 1180 |
| CDM200-4 | 200 | 138 | 77.9 | 93 | 2950 | 188.567 | 4 | -15℃～+70℃ | -15℃～+120℃ | 110 | CDLA-36/WB1F16 | 1180 |
| CDM125-1 | 125 | 24.5 | 78.9 | 10.6 | 2950 | 160 | 1 | -15℃～+70℃ | -15℃～+120℃ | 11 | CDM-22/WB1F14 | 264 |
| CDM125-2-2 | 125 | 33.5 | 76.3 | 15 | 2950 | 146 | 2 | -15℃～+70℃ | -15℃～+120℃ | 15 | CDM-22/WB1F14 | 291 |
| CDM125-2-1 | 125 | 41.5 | 78.8 | 18 | 2950 | 160 | 2 | -15℃～+70℃ | -15℃～+120℃ | 18.5 | CDM-22/WB1F14 | 299 |
| CDM125-2 | 125 | 50 | 81.8 | 20.8 | 2950 | 160 | 2 | -15℃～+70℃ | -15℃～+120℃ | 22 | CDM-22/WB1F14 | 352 |
| CDM125-3-1 | 125 | 67.5 | 81.9 | 28 | 2950 | 160 | 3 | -15℃～+70℃ | -15℃～+120℃ | 30 | CDM-22/WB1F14 | 423 |
| CDM125-3 | 125 | 76 | 82.9 | 31.2 | 2950 | 160 | 3 | -15℃～+70℃ | -15℃～+120℃ | 37 | CDM-22/WB1F14 | 443 |
| CDM125-4-2 | 125 | 84.5 | 81.6 | 35.3 | 2950 | 160 | 4 | -15℃～+70℃ | -15℃～+120℃ | 37 | CDM-22/WB1F14 | 453 |
| CDM125-4 | 125 | 101.5 | 83.4 | 41.5 | 2950 | 160 | 4 | -15℃～+70℃ | -15℃～+120℃ | 45 | CDM-22/WB1F14 | 551 |
| CDM125-5 | 125 | 127 | 83.7 | 51.7 | 2950 | 160 | 5 | -15℃～+70℃ | -15℃～+120℃ | 55 | CDM-22/WB1F14 | 622 |
| CDM125-6 | 125 | 152.5 | 83.8 | 62 | 2950 | 160 | 6 | -15℃～+70℃ | -15℃～+120℃ | 75 | CDM-28/WB1F14 | 777 |
| CDM125-7 | 125 | 178 | 83.8 | 72.3 | 2950 | 160 | 7 | -15℃～+70℃ | -15℃～+120℃ | 75 | CDM-28/WB1F14 | 788 |
| CDM125-8 | 125 | 203.5 | 83.9 | 82.6 | 2950 | 160 | 8 | -15℃～+70℃ | -15℃～+120℃ | 90 | CDM-28/WB1F14 | 819 |
| CDM125-9-2 | 125 | 210 | 82 | 87.2 | 2950 | 160 | 9 | -15℃～+70℃ | -15℃～+120℃ | 90 | CDM-28/WB1F14 | 832 |
| CDM125-9 | 125 | 229 | 83.9 | 93 | 2950 | 160 | 9 | -15℃～+70℃ | -15℃～+120℃ | 110 | CDM-28/WB1F14 | 1258 |
| CDM125-10 | 125 | 254.5 | 83.9 | 103 | 2950 | 160 | 10 | -15℃～+70℃ | -15℃～+120℃ | 110 | CDM-28/WB1F14 | 1268 |
| CDM155-1-1 | 155 | 18.5 | 72.5 | 10.8 | 2950 | 149 | 1 | -15℃～+70℃ | -15℃～+120℃ | 11 | CDM-22/WB1F14 | 265 |
| CDM155-1 | 155 | 27.5 | 77.9 | 15 | 2950 | 168.4 | 1 | -15℃～+70℃ | -15℃～+120℃ | 15 | CDM-22/WB1F14 | 280 |
| CDM155-2-2 | 155 | 37 | 75.2 | 20.8 | 2950 | 149 | 2 | -15℃～+70℃ | -15℃～+120℃ | 22 | CDM-22/WB1F14 | 352 |
| CDM155-2 | 155 | 55.5 | 81.1 | 28.9 | 2950 | 168.4 | 2 | -15℃～+70℃ | -15℃～+120℃ | 30 | CDM-22/WB1F14 | 412 |
| CDM155-3-2 | 155 | 65 | 79.3 | 34.6 | 2950 | 168.4 | 3 | -15℃～+70℃ | -15℃～+120℃ | 37 | CDM-22/WB1F14 | 443 |
| CDM155-3 | 155 | 83.5 | 82.3 | 42.9 | 2950 | 168.4 | 3 | -15℃～+70℃ | -15℃～+120℃ | 45 | CDM-22/WB1F14 | 541 |
| CDM155-4-1 | 155 | 102 | 80.5 | 53.5 | 2950 | 168.4 | 4 | -15℃～+70℃ | -15℃～+120℃ | 55 | CDM-22/WB1F14 | 611 |
| CDM155-5-2 | 155 | 120.5 | 81.2 | 62.6 | 2950 | 168.4 | 5 | -15℃～+70℃ | -15℃～+120℃ | 75 | CDM-28/WB1F14 | 766 |
| CDM155-5 | 155 | 139.5 | 82.8 | 71.2 | 2950 | 168.4 | 5 | -15℃～+70℃ | -15℃～+120℃ | 75 | CDM-28/WB1F14 | 767 |
| CDM155-6 | 155 | 167.5 | 82.8 | 85.4 | 2950 | 168.4 | 6 | -15℃～+70℃ | -15℃～+120℃ | 90 | CDM-28/WB1F14 | 798 |
| CDM155-7 | 155 | 195.5 | 82.9 | 99.6 | 2950 | 168.4 | 7 | -15℃～+70℃ | -15℃～+120℃ | 110 | CDM-28/WB1F14 | 1235 |
| CDM155-8-2 | 155 | 202 | 80.4 | 106 | 2950 | 168.4 | 8 | -15℃～+70℃ | -15℃～+120℃ | 110 | CDM-28/WB1F14 | 1246 |
| CDM185-1-B | 185 | 27.5 | 79.3 | 17.5 | 2950 | 172 | 1 | -15℃～+70℃ | -15℃～+120℃ | 18.5 | CDM-22/WB1F14 | 384 |
| CDM185-1-A | 185 | 34 | 79.8 | 21.5 | 2950 | 184.5 | 1 | -15℃～+70℃ | -15℃～+120℃ | 22 | CDM-22/WB1F14 | 438 |
| CDM185-2-2B | 185 | 57 | 82.8 | 34.7 | 2980 | 172 | 2 | -15℃～+70℃ | -15℃～+120℃ | 37 | CDM-22/WB1F14 | 535 |
| CDM185-2-2A | 185 | 71.5 | 83.5 | 43.2 | 2980 | 184.5 | 2 | -15℃～+70℃ | -15℃～+120℃ | 45 | CDM-22/WB1F14 | 635 |
| CDM185-3-3B | 185 | 86.5 | 83.2 | 52.4 | 2980 | 172 | 3 | -15℃～+70℃ | -15℃～+120℃ | 55 | CDM-22/WB1F14 | 707 |
| CDM185-3 | 185 | 115 | 84.6 | 68.5 | 2980 | 190 | 3 | -15℃～+70℃ | -15℃～+120℃ | 75 | CDM-28/WB1F14 | 865 |
| CDM185-4-A-3B | 185 | 120.5 | 84 | 72.3 | 2980 | 184.5 | 4 | -15℃～+70℃ | -15℃～+120℃ | 75 | CDM-28/WB1F14 | 886 |
| CDM185-4-3A-B | 185 | 135 | 84.1 | 81 | 2980 | 184.5 | 4 | -15℃～+70℃ | -15℃～+120℃ | 90 | CDM-28/WB1F14 | 907 |
| CDM185-4-4A | 185 | 142 | 84.1 | 85.1 | 2980 | 184.5 | 4 | -15℃～+70℃ | -15℃～+120℃ | 90 | CDM-28/WB1F14 | 907 |
| CDM185-5-2A-3B | 185 | 157.5 | 84.2 | 94.3 | 2980 | 184.5 | 5 | -15℃～+70℃ | -15℃～+120℃ | 110 | CDM-28/WB1F14 | 1382 |
| CDM185-5-5A | 185 | 178.5 | 84.8 | 106 | 2980 | 184.5 | 5 | -15℃～+70℃ | -15℃～+120℃ | 110 | CDM-28/WB1F14 | 1382 |
| CDM185-6-3A-3B | 185 | 190.5 | 84 | 114 | 2980 | 184.5 | 6 | -15℃～+70℃ | -15℃～+120℃ | 132 | CDM-36/WB1F14 | 1468 |
| CDM185-6-6A | 185 | 214 | 84.3 | 128 | 2980 | 184.5 | 6 | -15℃～+70℃ | -15℃～+120℃ | 132 | CDM-36/WB1F14 | 1469 |
| CDM185-7-4A-3B | 185 | 229.5 | 84 | 138 | 2980 | 184.5 | 7 | -15℃～+70℃ | -15℃～+120℃ | 160 | CDM-36/WB1F14 | 1607 |
| CDM185-7-7A | 185 | 251.5 | 84.7 | 150 | 2980 | 184.5 | 7 | -15℃～+70℃ | -15℃～+120℃ | 160 | CDM-36/WB1F14 | 1607 |
| CDM185-8-6A-2B | 185 | 271.5 | 84 | 163 | 2980 | 184.5 | 8 | -15℃～+70℃ | -15℃～+120℃ | 200 | CDM-36/WB1F14 | 1565 |
| CDM185-8-6A | 185 | 293 | 84.1 | 176 | 2980 | 190 | 8 | -15℃～+70℃ | -15℃～+120℃ | 200 | CDM-36/WB1F14 | 1574 |
| CDM185-8 | 185 | 317.5 | 84 | 191 | 2980 | 190 | 8 | -15℃～+70℃ | -15℃～+120℃ | 200 | CDM-36/WB1F14 | 1574 |
| CDM215-1-B | 215 | 28 | 77.6 | 21.1 | 2950 | 172.5 | 1 | -15℃～+70℃ | -15℃～+120℃ | 22 | CDM-22/WB1F14 | 437 |
| CDM215-1 | 215 | 42.5 | 81.5 | 30.6 | 2980 | 198 | 1 | -15℃～+70℃ | -15℃～+120℃ | 37 | CDM-22/WB1F14 | 517 |
| CDM215-2-2B | 215 | 57 | 81 | 41.2 | 2980 | 172.5 | 2 | -15℃～+70℃ | -15℃～+120℃ | 45 | CDM-22/WB1F14 | 635 |
| CDM215-2-A-B | 215 | 72 | 81.7 | 51.6 | 2980 | 194 | 2 | -15℃～+70℃ | -15℃～+120℃ | 55 | CDM-22/WB1F14 | 697 |
| CDM215-2 | 215 | 84.5 | 83.7 | 59.1 | 2980 | 198 | 2 | -15℃～+70℃ | -15℃～+120℃ | 75 | CDM-28/WB1F14 | 847 |
| CDM215-3-A-2B | 215 | 100.5 | 82.6 | 71.3 | 2980 | 194 | 3 | -15℃～+70℃ | -15℃～+120℃ | 75 | CDM-28/WB1F14 | 865 |
| CDM215-3-3A | 215 | 124 | 83.9 | 86.6 | 2980 | 194 | 3 | -15℃～+70℃ | -15℃～+120℃ | 90 | CDM-28/WB1F14 | 883 |
| CDM215-4-2A-2B | 215 | 143 | 83 | 101 | 2980 | 194 | 4 | -15℃～+70℃ | -15℃～+120℃ | 110 | CDM-28/WB1F14 | 1340 |
| CDM215-4 | 215 | 173.5 | 83.6 | 122 | 2980 | 198 | 4 | -15℃～+70℃ | -15℃～+120℃ | 132 | CDM-36/WB1F14 | 1428 |
| CDM215-5-3A-2B | 215 | 185 | 83.5 | 130 | 2980 | 194 | 5 | -15℃～+70℃ | -15℃～+120℃ | 132 | CDM-36/WB1F14 | 1447 |
| CDM215-5-5A | 215 | 203 | 83.8 | 142 | 2980 | 194 | 5 | -15℃～+70℃ | -15℃～+120℃ | 160 | CDM-36/WB1F14 | 1569 |
| CDM215-5 | 215 | 218.5 | 83.8 | 153 | 2980 | 198 | 5 | -15℃～+70℃ | -15℃～+120℃ | 160 | CDM-36/WB1F14 | 1569 |
| CDM215-6-3A-3B | 215 | 212 | 83 | 150 | 2980 | 194 | 6 | -15℃～+70℃ | -15℃～+120℃ | 160 | CDM-36/WB1F14 | 1589 |
| CDM215-6-5A-B | 215 | 241.5 | 83.5 | 169 | 2980 | 194 | 6 | -15℃～+70℃ | -15℃～+120℃ | 200 | CDM-36/WB1F14 | 1530 |
| CDM215-6 | 215 | 263.5 | 84.1 | 184 | 2980 | 198 | 6 | -15℃～+70℃ | -15℃～+120℃ | 200 | CDM-36/WB1F14 | 1530 |
| CDM215-7-5A-2B | 215 | 273 | 83.2 | 192 | 2980 | 194 | 7 | -15℃～+70℃ | -15℃～+120℃ | 200 | CDM-36/WB1F14 | 1548 |
客服1
